Visualization software PFSW315-PH7

monitoringmeasurementdata acquisition and analysis

Product overview
Energy Brain 7.X software with PostgreSQL database, supporting up to 16 channels for monitoring and managing the consumption of electrical energy and other energy sources (gas, water, steam, etc.), as well as environmental parameters (illuminance, temperature, thermal energy, compressed air, etc.).

Main functionality

• Historical data management with tabular and graphical reports
• Real-time measurements and monitoring
• Power Quality analysis from X3M devices
• Calendar management
• Cost center tracking
• Data export in common formats
• Additional advanced features for energy analysis and reporting

Licensing and delivery
Software is supplied with USB hardware license protection (USB dongle). Delivery includes license activation instructions and installation guidance.

Release 7.X improvements and device support
Release 7.X features a redesigned graphical user interface and improved processing speed. It supports the latest Electrex device families, including Kilo Net, Exa Net, Femto ECT Net, Yocto Net D6, Exa RS485, and RS485 Modules.

Channel management
Virtual channels are not counted against the total number of available channels, allowing flexible configuration and aggregation.

Optional modules and extensions

• Code: PFSW430-00 – Energy Brain Log Report Option: enables automatic sending of e-mail reports in various formats
• Code: PFSW400-00 – Energy Brain Personal Report Option: automates generation and distribution of energy reports (e.g. for energy consultants)
• Code: PFSW410-SK – Energy Brain Counters: generates reports containing energy meter readings from instruments at any selected site within the network
• Code: PFSWEC2-HK – Energy Brain Cloud: web access for viewing and managing real-time and historical data, measurements, and charts via PC, tablet, and smartphone

Documentation
Product datasheet "Energy Brain 7.x - Energy Brain Pro 7.x" available in PDF format for detailed information on features and options.

Characteristics / technical specifications

• Product code: PFSW315-PH7
• Commercial name: Energy Brain 7.X
• Database: PostgreSQL
• Maximum supported channels: up to 16 channels (virtual channels not counted)
• Monitored variables: electrical energy, gas, water, steam, illuminance, temperature, thermal energy, compressed air, etc.
• Historical data: tabular and graphical reports
• Real-time: live measurements and monitoring
• Power Quality: analysis from X3M devices
• Licensing: USB hardware license protection (USB dongle)
• Release notes: redesigned GUI and improved processing speed in Release 7.X
• Supported device families: Kilo Net, Exa Net, Femto ECT Net, Yocto Net D6, Exa RS485, RS485 Modules
• Virtual channels: do not count against total available channels
• Optional modules: PFSW430-00 (Log Report), PFSW400-00 (Personal Report), PFSW410-SK (Counters), PFSWEC2-HK (Cloud)
