Visualization software PFSWP310-PH7

monitoringdata acquisition and analysisdata acquisition

Product overview
Code: PFSWP310-PH7
Energy Brain Pro 7.X with PostgreSQL database. Supports up to 8 channels to monitor and manage electrical energy and other energy sources (gas, water, steam) and environmental parameters (illuminance, temperature, thermal energy, compressed air). Designed for industrial energy monitoring and reporting.

Key features

• Historical data management with tabular and graphical reports
• Real-time measurements and visualization
• Power Quality analysis (integration with X3M devices)
• Calendar and event scheduling
• Cost center management and logging
• Data export in common formats
• Alarm and event log

Pro version advanced features

• Multi-tab views for parallel dashboards
• Multi-period analysis and comparative reports
• Import/export energy visualization and reconciliation
• Operating time and uptime monitoring
• Validation of acquired data
• Acquisition of external data from databases or archives (e.g. operating hours, production quantities, baseline/KPI)

License
Software is protected by a USB hardware license key (dongle).

Optional modules

• PFSW430-00 – Energy Brain Log Report Option: automatic sending of e-mail reports in multiple formats
• PFSW400-00 – Energy Brain Personal Report Option: automated generation and distribution of energy reports (e.g. for energy consultants)
• PFSW410-SK – Energy Brain Counters: generation of reports containing meter readings for selected sites in the network
• PFSWEC2-HK – Energy Brain Cloud: web-browser access (PC, tablet, smartphone) to real-time and historical data, measurements and charts from Electrex instruments

Technical specifications

• Product code: PFSWP310-PH7
• Product name: ENERGY BRAIN PRO 7.X
• Database: PostgreSQL
• Channels supported: up to 8 channels
• Measured resources: electrical energy, gas, water, steam, etc.
• Environmental parameters: illuminance, temperature, thermal energy, compressed air, etc.
• Historical reporting: tabular and graphical reports
• Real-time measurements supported
• Power Quality analysis: integration with X3M devices
• License protection: USB hardware dongle
• Pro features: multi-tab, multi-period, import/export visualization, operating time monitoring, data validation, external data acquisition
• Optional modules: PFSW430-00, PFSW400-00, PFSW410-SK, PFSWEC2-HK
