Visualization software PFSW190-PH7

monitoringdata acquisition and analysisdatabase

Overview
Code: PFSW190-PH7
Energy Brain 7.X software with PostgreSQL database, supporting up to 300 channels for monitoring and managing consumption of electrical energy and other energy sources (gas, water, steam, etc.) and environmental parameters (illuminance, temperature, thermal energy, compressed air, etc.).

Main features

• Historical data management with tabular and graphical reports
• Real-time measurements and on-line monitoring
• Power Quality analysis (from X3M devices)
• Calendar management and scheduling
• Cost center structuring for site accounting
• Data export for external analysis
• Additional advanced reporting and analysis tools

Licensing and delivery
The software is supplied with USB hardware license protection.

Release 7.X improvements and supported devices
Redesigned graphical user interface and improved processing speed. Release 7.X adds support for the latest Electrex device families: Kilo Net, Exa Net, Femto ECT Net, Yocto Net D6, Exa RS485 and RS485 Modules.

Channels and virtual channels
Virtual channels are no longer counted against the total number of available channels (they do not reduce the number of monitored channels included in the product channel limit).

Optional modules (expandable functionality)

• PFSW430-00 – Energy Brain Log Report Option: enables automatic sending of e-mail reports in various formats
• PFSW400-00 – Energy Brain Personal Report Option: automates generation and distribution of energy reports (suitable for energy consultants)
• PFSW410-SK – Energy Brain Counters: generates reports containing meter readings from all instruments installed at any selected site in the network
• PFSWEC2-HK – Energy Brain Cloud: web-based access via standard browsers on PC, tablet and smartphone for real-time and historical data, measurements and charts

Technical characteristics / specifications

• Code: PFSW190-PH7
• Commercial name / model: Energy Brain 7.X (ENERGY BRAIN 300)
• Database: PostgreSQL
• Maximum supported channels: up to 300 channels
• Virtual channels: not counted against the total channel limit
• Measured sources supported: electrical energy, gas, water, steam, thermal energy, compressed air, illuminance, temperature and other environmental parameters
• Power Quality: analysis supported (from X3M devices)
• License protection: USB hardware key
• Release improvements: redesigned GUI and improved processing speed; support for Kilo Net, Exa Net, Femto ECT Net, Yocto Net D6, Exa RS485, RS485 Modules
• Expandable via optional modules: log reporting, personal reporting, counters, cloud management
