Monitoring software package PFSWP190-PH7 ENERGY BRAIN PRO 300 7.X HK POSTGRESQL

data acquisition and analysisdata acquisitiondatabase

Product overview
Code: PFSWP190-PH7
Energy Brain Pro 7.X software with PostgreSQL database supporting up to 300 channels for monitoring and managing electrical energy and other energy sources (gas, water, steam) and environmental parameters (illuminance, temperature, thermal energy, compressed air).

The software provides

• Historical data management with tabular and graphical reports
• Real-time measurements
• Power quality analysis from X3M devices
• Calendar and event management
• Cost centre configuration
• Data export in common formats
• Additional advanced utilities for industrial energy monitoring

Pro version - advanced features

• Multi-tab views for parallel analyses
• Multi-period comparison and trending
• Import/export energy visualization (Import/Export energy flows)
• Operating time and runtime monitoring
• Validation and processing of acquired data
• Acquisition of external data from databases or archives (e.g. operating hours, production quantities, baseline/KPI values)

License
Software supplied with USB hardware license protection.

Expandability / Optional modules

• Code: PFSW430-00 – Energy Brain Log Report Option: automatic sending of e-mail reports in various formats.
• Code: PFSW400-00 – Energy Brain Personal Report Option: automation of generation and distribution of energy reports (e.g. for energy consultants).
• Code: PFSW410-SK – Energy Brain Counters: report generation from meter readings of instruments installed at selected sites.
• Code: PFSWEC2-HK – Energy Brain Cloud: browser-based access (PC, tablet, smartphone) to real-time and historical data, measurements and charts.

Documentation
Product data sheet available (PDF).

Characteristics / Technical specifications

• Product name: Energy Brain Pro 7.X
• Code: PFSWP190-PH7
• Database: PostgreSQL
• Channels supported: up to 300 channels
• Monitored energy sources: electrical energy, gas, water, steam, etc.
• Monitored environmental parameters: illuminance, temperature, thermal energy, compressed air, etc.
• Main functions: historical data management (tabular and graphical reports), real-time measurements, power quality analysis (from X3M devices), calendar and event management, cost centres, data export
• Pro advanced features: multi-tab views, multi-period analysis, import/export energy visualization, operating time monitoring, data validation, acquisition from external databases/archives
• License protection: USB hardware license
• Optional modules: PFSW430-00 (Log Report), PFSW400-00 (Personal Report), PFSW410-SK (Counters), PFSWEC2-HK (Cloud)
