DC servo-amplifier / brushless / 1-axis
EA47

Add to MyDirectIndustry favorites
DC servo-amplifier / brushless / 1-axis DC servo-amplifier / brushless / 1-axis - EA47
{{requestButtons}}

Characteristics

  • AC/DC:

    DC

  • Type:

    brushless

  • Number of axes:

    1-axis

  • Current:

    9 A, 18 A

  • Output power:

    1,260 W (1.71312 hp)

Description

This four-quadrant brushless DC servo amplifier comes with a Brushless Servo-PWM technology. The device has 4 quadrants and offers a nominal current of 9 and 18A. It is housed in a solid aluminum case. This case offers easy integration as it can be DIN-rail mounted or panel mounted. This feature allows for easy integration. It is easy to configure and offers various torque and speed control modes. DIP switches are used to make such changes. Both the versions of this device come with adjustable current limit. 9 - 70 VDC range of supply voltage can be used to fulfill the power requirements.

This four-quadrant brushless DC servo amplifier is safe to use as it provides protection against over-current and over-temperature and motor short-circuit. It provides superior performance through its MOSFET technology. The device comes with RJ45-CAT5 connectors for tool free connectivity.
