High-performance fan EDM series

high-flowaxialcooling

Overview
DC-voltage brushless fans with mechanical metal impellers and metal frames, available in large sizes (≥ 92 mm). Designed for industrial cooling applications requiring high airflow and durable construction. Multiple models cover a wide range of dimensions and performance levels.

Specification

• ED2890M — 280 x 280 x 88.9 mm (11.004 x 11.004 x 3.5 in) — Max airflow: 34 ~ 22.1 m³/min (1200 ~ 780 CFM).
• ED2589M — Ø254 x 89 mm (Ø10 x 3.5 in) — Max airflow: 29.2 ~ 19.3 m³/min (1030 ~ 680 CFM).
• ED2280M — 225 x 225 x 80 mm (8.85 x 8.85 x 3.15 in) — Max airflow: 19.7 ~ 7.6 m³/min (695 ~ 270 CFM).
• ED2172M — 205 x 205 x 72 mm (8.1 x 8.1 x 2.8 in) — Max airflow: 18.4 ~ 9.9 m³/min (650 ~ 350 CFM).
• ED1865M — 180 x 180 x 65 mm (7 x 7 x 2.5 in) — Max airflow: 13.6 ~ 6.2 m³/min (480 ~ 220 CFM).
• ED1555M — 172 x 150 x 55 mm (6.70 x 5.90 x 2.16 in) — Max airflow: 8.8 ~ 4.4 m³/min (310 ~ 155 CFM).
• ED1751M — Ø172 x 51 mm (Ø6.7 x 2.0 in) — Max airflow: 9.1 ~ 4.1 m³/min (320 ~ 145 CFM).
• ED1551M — 172 x 150 x 51 mm (6.70 x 5.90 x 2.00 in) — Max airflow: 9.1 ~ 4.2 m³/min (320 ~ 150 CFM).
• ED1538M — 172 x 150 x 38 mm (6.70 x 5.90 x 1.50 in) — Max airflow: 7.4 ~ 3.7 m³/min (260 ~ 130 CFM).
• ED1238M — 120 x 120 x 38 mm (4.70 x 4.70 x 1.50 in) — Max airflow: 4 ~ 2.7 m³/min (140 ~ 94 CFM).
• ED9238M — 92 x 92 x 38 mm (3.62 x 3.62 x 1.50 in) — Max airflow: 2.3 ~ 1.6 m³/min (82 ~ 58 CFM).

Notes

• We reserve the right to change the data without further notice.
• Performance data subject to ±10% tolerance.
• Optional: signal output, speed control and IP rating available on request.

Technical characteristics

• Operating voltage: DC (brushless motor).
• Impeller: Metal impeller (mechanical revolving metallic blade).
• Frame: Metal frame.
• Available sizes: from 92 x 92 x 38 mm up to 280 x 280 x 88.9 mm.
• Model prefix: ED (examples: ED9238M, ED1238M, ED1538M, ED1551M, ED1555M, ED1751M, ED1865M, ED2172M, ED2280M, ED2589M, ED2890M).
• Max airflow range by model: approx. 2.3 ~ 34 m³/min (approx. 58 ~ 1200 CFM) depending on model.
• Tolerances and options: performance ±10%; optional signal output, speed control and IP ratings on request.
