Cabling trunking - SR1732 - Essentra Components - PVC / polypropylene / fire-resistant

Characteristics

Function

cabling

Material

PVC, polypropylene

Other characteristics

fire-resistant

Width

Min.: 7.6 mm
(0.3 in)

Max.: 2,040 mm
(80.31 in)

Height

Min.: 10.2 mm
(0.4 in)

Max.: 76.2 mm
(3 in)

Length

Min.: 110 mm
(4.33 in)

Max.: 2,040 mm
(80.31 in)

Description

Product Details
Cable Duct is a versatile cable management product. With both adhesive and screw mounting options available there is added flexibility in the application.

Available Variants (Selection)

Adhesive Mount and Screw Mount options
Various lengths: 1.8 m, 2.0 m, 500.0 mm, 185.0 mm, 320.0 mm, 720.0 mm, 110.0 mm, 1320.0 mm, 2040.0 mm, etc.
Various widths: 7.6 mm, 9.1 mm, 15.9 mm, 19.1 mm, 20.7 mm, 25.1 mm, 28.6 mm, 38.1 mm, 50.8 mm, 101.6 mm, 110.0 mm, 185.0 mm, 320.0 mm, 500.0 mm, 720.0 mm, 1320.0 mm, 2040.0 mm
Various heights: 10.2 mm, 14.7 mm, 20.8 mm, 38.1 mm, 50.8 mm, 76.2 mm
Colours: Grey, Tan
Materials: Polypropylene, Polyvinyl Chloride (PVC), Acrylic Adhesive
UL94 V-0 flame rating available on some variants

Mounting Methods

Adhesive
Adhesive Mount
Screw
Screw Mount

Example Attributes (per variant)

Colour: Grey or Tan
Full Material: Polypropylene or Polyvinyl Chloride
Base Material: Acrylic Adhesive (for adhesive variants)
Inside Width: e.g. 7.283 in / 185.0 mm
Overall Length: e.g. 19.685 in / 500.0 mm
Inside Height: e.g. 0.402 in / 10.2 mm
Overall Width: e.g. 0.299 in / 7.6 mm

Stock and Pricing (examples)

Price range: from 3,4074 € to 408,4416 € depending on variant
Stock levels: from 1 to 9294 units in stock depending on variant

Characteristics / Technical Specifications

Product type: Cable Duct
Mounting: Adhesive or Screw
Material: Polypropylene, Polyvinyl Chloride, Acrylic Adhesive
Colour: Grey, Tan
Available lengths: 1.8 m, 2.0 m, 500.0 mm, 185.0 mm, 320.0 mm, 720.0 mm, 110.0 mm, 1320.0 mm, 2040.0 mm, etc.
Available widths: 7.6 mm, 9.1 mm, 15.9 mm, 19.1 mm, 20.7 mm, 25.1 mm, 28.6 mm, 38.1 mm, 50.8 mm, 101.6 mm, 110.0 mm, 185.0 mm, 320.0 mm, 500.0 mm, 720.0 mm, 1320.0 mm, 2040.0 mm
Available heights: 10.2 mm, 14.7 mm, 20.8 mm, 38.1 mm, 50.8 mm, 76.2 mm
UL94 V-0 flame rating: Available on some variants
