Electric cut-off saw RCS-75NC

hydraulicfor metalsfor steel

Product
RCS-75NC fully automatic high-speed metal circular saw machine for cutting round and square bars, suitable for continuous production lines.

Table: Saw range and length
project | unit | specifications
Saw cut range | mm | Round Ø10–Ø70; Square 10–55
The length of the cut | mm | 5–800 (continuous cycle action)

Table: Feed and saw parameters
feed | |
Feed accuracy of wire rod | mm | ±0.05
Swing off (vertical to the axis) | mm | ≤0.1/100
Clamping method | | Horizontal, upper clamp pressure
Saw blade specification | mm | 285 × 2 × 1.7
Saw speed | r/min | 30–160 (variable frequency)
Motor power | kW | 11 (permanent magnet)
Hydraulic system pressure | MPa | 6.5

Table: Drive, fluids, dimensions and weight
Feed drive | kW | 0.85 (servo motor, ball screw)
Saw cut drive | kW | 1.3 (servo motor, ball screw)
Hydraulic oil tank volume | L | 62
Compressed air | bar | 4.5–6
Discharge method | | Automatic screw chip transmitter
External size | mm | H=1700 W=2100 L=2300
Net weight (host + rack) | kg | 1800 + 550

Features / technical specifications

• Saw cut range: Round Ø10–Ø70 mm; Square 10–55 mm
• Cut length: 5–800 mm (continuous cycle)
• Feed accuracy of wire rod: ±0.05 mm
• Swing off (vertical to the axis): ≤0.1/100 mm
• Clamping method: Horizontal with upper clamp pressure
• Saw blade specification: 285 × 2 × 1.7 mm
• Saw speed: 30–160 r/min (variable frequency)
• Motor power: 11 kW (permanent magnet)
• Hydraulic system pressure: 6.5 MPa
• Feed drive: 0.85 kW (servo motor, ball screw)
• Saw drive: 1.3 kW (servo motor, ball screw)
• Hydraulic oil tank volume: 62 L
• Compressed air requirement: 4.5–6 bar
• Discharge method: Automatic screw chip transmitter
• External dimensions (HxWxL): 1700 × 2100 × 2300 mm
• Net weight (host + rack): 1800 + 550 kg
