Air wipe shim set Model 2354 Standard

Description
The Standard Air Wipe Shim Set adjusts the exhaust gap on EXAIR Standard Air Wipes to control air force and flow. The Air Wipe ships with a .002" (0.05 mm) plastic shim installed that suits most applications; adding shims opens the gap to increase force and flow. Shim Sets include two each of .001" (0.03 mm), .003" (0.08 mm) and .004" (0.10 mm) plastic shims. Shim sets are supplied with kits or sold separately.

Systems

• Standard Air Wipe Only
• Standard Air Wipe Kits - includes a Standard Air Wipe, shim set, filter separator and pressure regulator (with coupler)
• Standard Air Wipe Shim Sets - include two each of .001" (0.03 mm), .003" (0.08 mm) and .004" (0.10 mm) plastic shims

How it works
Compressed air enters the Air Wipe inlet and fills an annular chamber. It is throttled through a ring nozzle at high velocity and follows the Coanda profile, directing the primary airstream down the angled surface. A low-pressure area at the center induces a high volume of ambient air into the primary stream. The combined flow exits as a 360° conical ring of high-velocity air that uniformly wipes the surface of material passing through the Air Wipe.

Available I.D. / Model numbers
I.D. | Standard Air Wipe Only | Standard Air Wipe Kit | Standard Air Wipe Shim Set
1/2" (13 mm) | 2430 | 2480 | 2350
1" (25 mm) | 2431 | 2481 | 2351
2" (51 mm) | 2432 | 2482 | 2352
3" (76 mm) | 2433 | 2483 | 2353
4" (102 mm) | 2434 | 2484 | 2354
5" (127 mm) | 2435 | 2485 | 2355
6" (152 mm) | 2436 | 2486 | 2356
7" (178 mm) | 2437 | 2487 | 2357
9" (229 mm) | 2439 | 2489 | 2359
11" (279 mm) | 2441 | 2481 | 2361

Included with Shim Set
Shim Sets include two of each: .001" (0.03 mm), .003" (0.08 mm), and .004" (0.10 mm) plastic shims.

Technical specifications

• Product name: Standard Air Wipe Shim Set
• Brand: EXAIR
• Product SKU / Model: P2351
• Included shims: (2) x .001" (0.03 mm), (2) x .003" (0.08 mm), (2) x .004" (0.10 mm); shipped with installed .002" (0.05 mm) plastic shim
• Function: Sets exhaust gap on Standard Air Wipe to control force and flow; add shims to increase force/flow
• Application: Blow off, cooling and drying; creates a 360° ring of high-velocity airflow that uniformly wipes the surface of material passing through it
• Packaging: Shim Set sold separately or included with Standard Air Wipe Kits
