Access control light curtain X-Guard

safetymultibeam

Overview
Horizontal safety sensor for barriers providing opening control and presence/safety maintenance in vehicle access areas.

Performance

• Dual function: barrier opening and presence/safety maintenance
• Alternative to cutting inductive loops into the road surface
• Detects all vehicle types, including electric and composite-bodied vehicles, and trucks with trailers
• Trajectory detection: detects approach and moving-away to reduce false barrier raises
• Pedestrian screening: suppresses false activations caused by pedestrians in the opening area
• Maximum detection field: 9.9 m × 9.9 m
• LED indicators can be switched off for discreet installation

Variants

• X-Guard Barrier 10H Sensor | N-105043
• Mounting Bracket | N-785031
• Post & Housing | N-XGPOST
• Programmer Remote | N-02.0103

Documents available
Datasheet, user manual and post dimensions are available for this product.

Technical specifications

• Function: horizontal safety sensor for barriers (opening control and presence/safety maintenance)
• Maximum detection field: 9.9 m × 9.9 m
• Vehicle detection: suitable for electric vehicles, composite-bodied vehicles, and trucks with trailers
• Trajectory detection: detects both approach and moving-away to minimize false barrier openings
• Pedestrian screening: prevents activations caused by pedestrians within the opening area
• LED indicators: can be disabled to reduce visual impact
• Installation benefit: alternative to road loop cutting for vehicle detection
