Special Features:
Fanless, Low Power
Applications:
Factory e-automation、Home Automation、Digital Signage、Gaming
Function Items - Specifications
Processor - AMD Geode LX-800
Operating Freq. (Hz) - 500MHz
Chipset - AMD Geode LX-800 + CS5536
BUS I/F - PC/104
L2 Cache - 128KB
On-Board DRAM - -
DRAM Socket - 200-Pin SoDIMM *1 (DDR, 1GB Max)
VGA Chipset - AMD Geode LX-800
VRAM - UMA 254MB Max
Display - VGA、LCD
Dual Display - -
Audio - Yes (Option)
Serial Port - RS232 *2
Parallel Port - -
FDC / IDE - No / Yes (PATA)
KB / Mouse - Yes
LAN - 1 (10/100 Base-T)
USB - 2 (2.0)
GPIO - -
WDT / HWM - Yes / No
Flash/Memory Socket - CF Socket *1
BIOS - Phoenix
Power Required - +5V Only, 6.5VA Max
Operation System - Windows 2K / XP / XPe / CE, and Linux
Operation Temperature - 0°C to 60°C (32℉ to 140℉)
Compliances - RoHS
Dimension - 90.2 x 95.9 mm
