Wall-mounted fan GDS Serieslow-noiseIP44centrifugal
Add to favorites
Compare this product
Characteristics
- Type
- wall-mounted, low-noise, IP44
- Configuration
- centrifugal
- Function
- cooling, extraction
- Supply voltage
- 230VAC
- Drive mechanism
- with asynchronous motor
- Other characteristics
- flange, with external rotor
- Air flow
Min.: 415 m³/h
(14,655.587 ft³/h)Max.: 1,115 m³/h
(39,375.853 ft³/h)- Rotational speed
Min.: 1,620 rpm
(10,179 rad.min-1)Max.: 2,355 rpm
(14,797 rad.min-1)
Description
Double inlet centrifugal fans, with and without flange, are used for air extraction in applications requiring high operating performance. These fans are equipped with a double shaft motor mounted on plastic supports, which minimise the transfer of mechanical noise generated by the rotation of the impeller and reduce the possibility of unbalance of the same. Voltage control can be used to modulate the rotation speed and the noise level of the double inlet fans. The double inlet fan motors are equipped with integrated thermal protection to protect them from damage and malfunctions.
