Thermostatic test chamber TB-TS

temperaturehumiditystability

Overview Precise temperature control for stability testing, thermal cycling and shock testing. Ideal for electronics, components and materials. Produced by FDM, an Italian manufacturer since 1949.

Applications

• Stability testing
• Thermal cycling and shock tests
• Electronics, components and semiconductor validation
• Materials research and quality validation

Key features

• Available internal volumes from compact to large laboratories
• Temperature range suitable for a wide set of laboratory tests
• Forced ventilation for homogeneous temperature distribution
• Low-maintenance design with optimized energy consumption
• Class 2 safety devices and audiovisual alarms (DIN 12880)

Controllers stillFACE

• Dual dedicated displays for temperature and humidity, manual setting, continuous monitoring and configurable audio-visual alarms for long-term stability tests

revoFACE

• Programmable color touchscreen for complex cycles (ramps, pauses, transitions) with USB export, RS485/Ethernet and mobile app connectivity for automated cyclic and shock tests

Standards & documentation

• Designed to comply with DIN 12880, IEC 60068 and MIL-STD-883 test needs
• IQ/OQ documentation available on demand
• ISO 9001 manufacturer; product made in Italy; warranty and factory test procedures available

Technical specifications

• Denomination: TB-TS Series
• Available internal volumes: 140, 300, 700, 1500, 2300 L
• Temperature range: -25°C / +70°C
• Temperature uniformity: ±0.5 – ±2.5°C
• Temperature fluctuation (stability): ±0.1 – ±0.5°C
• Heating speed (ramp): 2°C/min
• Cooling speed: 2°C/min
• Internal material: AISI 304 stainless steel
• Insulation: CFC and HCFC-free
• Ventilation: forced ventilation for homogeneous distribution
• Shelf capacity: up to 30 kg per shelf (max, model dependent)
• Safety: Class 2 devices (DIN 12880), audiovisual alarms and independent limiters
• Controllers: revoFACE (programmable) and stillFACE (constant monitoring)
• Power supply: 230 V 50 Hz (single phase)
