Climate chamber Solarbox Module

thermostatictemperaturehumidity

Product overview
High‑precision xenon solar simulation chamber for photostability, accelerated aging and UV‑resistance testing. Equipped with a 1600 W air‑cooled xenon lamp, BPT (black panel temperature) control up to +98°C and controlled humidity to reproduce realistic solar exposure in accelerated test cycles. Modular internal volumes from 140 to 2300 L and an exhibition area of ~600 cm² (30 × 20 cm) for samples.

Standards and compliance
Designed to support tests compliant with ICH Q1B, ISO 4892, ASTM G155 and ISO 11341. IQ/OQ documentation and a full PDF datasheet are available on request to assist validation and regulatory submissions.

Main features

• 1600 W air‑cooled xenon lamp providing full‑sun spectrum (UV–VIS–IR).
• BPT control up to +98°C (typical control range available +60°C → +98°C).
• Controlled humidity 10–50% RH with options for active humidity control and deep dehumidification down to ~2% RH.
• Interchangeable optical filters: Daylight and Window Glass (300–800 nm irradiance control).
• Daylight irradiance (300–800 nm): ~352 – 819 W/m²; Window Glass irradiance (300–800 nm): ~328 – 769 W/m².
• Daylight illumination range: ~75K – 134 Klx (max illumination up to 134 Klx).
• Integrated spray system for rain/condensation simulation (front and rear spray; optional 16 L tank).
• Optional water‑cooled sample table for contact cooling of heat‑sensitive specimens.
• Exhibition/sample area ~600 cm² (30 × 20 cm).
• Lamp life typically 1,500–2,000 hours; intensity monitoring with optional irradiance sensor recommended for lamp replacement planning.

Controllers and user interface

• stillFACE controller — two dedicated displays for temperature and humidity: manual setpoints, high‑visibility LCDs, continuous monitoring, configurable audio‑visual alarms, optional RS485 for data logging. Suited to stability testing and passive monitoring.
• revoFACE controller — 7" color touchscreen for cyclic programming: intuitive interface, up to 10 programs × 50 segments (cycles from 1 min to 999 h), ramps/stasis/transitions, USB data export, event log, RS485/Ethernet and dedicated mobile app. Ideal for automated cycles and advanced programmed tests.

Additional capabilities

• Integrated options and accessories: IQ/OQ certification package, ventilation filters, cable pass‑throughs, glass door, internal electrical socket, self‑locking swivel wheels, water filtration, CO2 regulation system.
• Operational modes: BPT‑based control (temperature measured on black panel) to reproduce combined radiation and thermal effects; water‑cooled table option to separate radiative and conductive thermal effects.
• Spray cycles to reproduce alternating sunlight and moisture exposure for accelerated identification of material weaknesses.

Technical data (quick view)
Model: Solarbox Module (Xenon Solar Test Chamber)
Lamp power: 1600 W (air‑cooled xenon)
Available volume: 140 – 2300 L (configurable)
Maximum BPT: +60°C – +98°C (control up to +98°C)
Humidity control: 10 – 50% RH (options for lower RH and dehumidification to ~2%)
Daylight irradiance (300–800 nm): 352 – 819 W/m²
Window Glass irradiance (300–800 nm): 328 – 769 W/m²
Daylight illumination: 75K – 134 Klx
Exhibition area: ~600 cm² (30 × 20 cm)
Lamp life: 1500 – 2000 hours
Standards: ICH Q1B, ISO 4892, ASTM G155, ISO 11341

Notes
IQ/OQ documentation and a full technical datasheet (PDF) are available on request. The chamber is modular and configurable (volume, filters, accessories, controllers) to meet laboratory test plans and regulatory requirements.
