Walk-behind scrubber-dryer V1

electricDCbattery-powered

Overview
V1 professional vertical autoscrubber. A compact solution for cleaning small and medium floors that adapts to confined spaces and complex layouts. V1 delivers the cleaning performance of a conventional scrubber dryer in a nimble, easy-to-manoeuvre vertical machine, allowing access to narrow passages and hidden corners for professional-level hygiene.

Technologies

• WEIGHTLESS TECHNOLOGY: reduces perceived machine weight for easier handling
• ECO Mode: saves water and detergent and reduces noise
• Li-ion technology: fast recharging for improved machine availability

Highlights

• Construction suited for professional use
• High cleaning performance in a compact vertical layout
• Extended operating autonomy with lithium battery options
• Protection of components from water to increase reliability
• Ergonomic design compliant with applicable standards
• Weightless joint that reduces operator strain
• Two operating modes to adapt to different cleaning needs
• Machine stands upright for compact storage
• Easy switching between working modes and squeegee lowering
• Driving dashboard handle designed to help maintain correct posture
• Quick&Smart solutions for immediate readiness without extensive operator training
• Quick-stand recovery and solution tanks for easy setup and maintenance
• Designed to increase productivity
• Small environmental footprint

Technical data (table)
Productivity (up to sqm/h): 1380
Working width (mm): 460
Brush motors (no.) V/W: (2) 24/310
Brush speed (rpm): 350
Pressure on the brushes (kg): 30
Solution tank (l): 5
Recovery tank (l): 6
Suction motor (V/W): 24/200
Supply/traction (V/Hz): 24 / Semi aut.
Battery / Run time (no.) V/Ah / h: (1) Lithium 24/15 / 1h (60’) ; (1) Lithium 24/25 / 2h (120’)
Machine dimensions (L x h x w) (mm): 505 x 1170 x 470
Squeegee width (mm): 505
Machine weight empty without batteries (kg): 24
Sound pressure level (ISO 11201 – LpA - Eco mode dB(A)): <70

Technical specifications

• Productivity (up to sqm/h): 1380
• Working width: 460 mm
• Brush motors: 2 units, 24 V / 310 W
• Brush speed: 350 rpm
• Pressure on the brushes: 30 kg
• Solution tank capacity: 5 L
• Recovery tank capacity: 6 L
• Suction motor: 24 V / 200 W
• Supply/traction: 24 V / Semi automatic
• Battery options and run time: Lithium 24 V / 15 Ah → approx. 1 h (60'); Lithium 24 V / 25 Ah → approx. 2 h (120')
• Machine dimensions (L × H × W): 505 × 1170 × 470 mm
• Squeegee width: 505 mm
• Machine weight (empty, without batteries): 24 kg
• Sound pressure level (Eco mode): <70 dB(A)
