Belt-drive linear module FBL80

guidefor welding applications

Belt-driven linear actuator from the FBL80 series designed for long-stroke, high-speed linear motion with stepper motor drive. The FBL80 fully sealed linear guide (80 mm body width) prevents dust and debris ingress for reliable operation in harsh or dusty environments.

Main features

• Series: FBL80
• Body width: 80 mm
• Fully sealed, dust-proof linear guide
• Large extension, minimal compression
• Resistant to deformation from hard-object collisions
• Oleic acid resistance and high-temperature resistance
• Engineered for long service life in industrial applications

Application area
Suitable for automated processes and equipment requiring long-stroke, dustproof linear motion, including:

• Automatic dispensing and spray coating
• Welding and packaging machines
• Material handling and printing equipment
• Laser carriers and photovoltaic back-sheet cutting/cutting machines
• Conveyor robots, time-lapse rigs and auxiliary automation equipment
• Electrical research, test demonstrations and diverse industrial automation production lines

Technical specifications

• Series: FBL80
• Stroke range: 100 mm – 12,000 mm
• Position accuracy: 0.05 mm
• Max speed: 2000 mm/s
• Max load: 30 kg
• Synchronous wheel circumference: 165 mm
• Body width: 80 mm
• Structure: Fully sealed, dust-proof
• Resistance: Oleic acid resistance; high-temperature resistance
• Durability: Long service life; resistant to deformation from hard collisions
