O-ring seal GT2020lippedflatsilver
Add to favorites
Compare this product
Characteristics
- Type
- O-ring, lipped, flat
- Material
- silver, elastomer, silicone
- Configuration
- round, with circular cross section, U-shaped, profiled, V, triangular, tadpole, rectangular, grooved, tubular, X-ring, Y, D-shaped, C, X, L, T-shaped, I
- Application
- housing, industrial, for mechanical components, for medical applications, for industrial applications, for high-temperature applications, flange, for aerospace applications, for electronic applications, industrial, rugged, for railway applications, for automotive applications, for motors, for automobiles, for electronic components, EMC shielding, for connectors, electronic equipment, for marine applications, for aeronautical applications, for medical equipment
- Other characteristics
- custom-made, high-temperature, extruded, molded, conductive
- Temperature limit
Max.: 160 °C
(320 °F)Min.: -55 °C
(-67 °F)- Shore A hardness
75 unit
Description
GT2020 is an EMC conductive gasket developed from a pure silver filled conductive silicone.
Thanks to its ESA-ECSS-Q-ST-70-02C certifications, GT2020 is suitable for aerospace applications.
GT2020 offers highly conductivity, very low resistivity, excellent attenuation performance and high temperature resistance (peak at 200°C).
Forming options: Custom molded, die-cut, extruded, sheeted, or vulcanized.
Technical data for the GT2020 conductive EMC gasket:
Volume resistivity (ohm.cm) = <0.006
Hardness (Shore A) = 75
Density (g/cm3) = 3.90
Break resistance (Mpa) = 4.61
Tear resistance (N/mm) = 13.73
Continuous operating temperature (°C) = -55°C to +160°C (peak at 200°C)
Learn more about our conductive elastomer range:
Getelec develops and manufactures conductive EMC solutions based on silicone and fluorosilicone filled with conductive particles such as silver-plated copper, silver, silver-plated nickel, graphite nickel, aluminum nickel, silver-plated aluminum, treated aluminum, carbon, or silver-plated glass beads to ensure optimal galvanic and electromagnetic compatibility.
This expertise allows us to define the ideal material based on your equipment and specifications, in order to offer you a customized conductive solution tailored to your needs.
