Crimping press GM49manualhand-operatedwith lever control
Add to favorites
Compare this product
Characteristics
- Operation
- manual
- Function
- crimping
- Control
- hand-operated
- Other characteristics
- with lever control
- Applications
- for electrical connectors
- Stroke
15 mm
(1 in)- Weight
10 kg
(22 lb)
Description
The MANUAL CRIMPING PRESS GM49 crimping press has been designed to crimp insulation displacement connectors (IDC) on flat cable.
Besides, any crimping on loose terminals is possible, as much as it to make any kind of working on cables including the notching.
Its riduced dimensions and weight (10 Kg. Approx) allow the easy moving on the equipment wherever it is needed.
The crimping process is completely manual (throught clamp lever).
The MANUAL CRIMPING PRESS GM49 is provided with punch and suitable dies for the connector or for the required item.
ALIMENTATION - No
PNEUMATIC ALIMENTATION - No
ABSORBMENT - No
CRIMPING FORCE - Manual
WORKABLE TERMINALS - 50 mm
STROKE - 15 mm
WORKABLE TERMINALS - Whatever
PRODUCTIVITY - Not Definable
DISPLAY - No
WEIGHT - 10 Kg
DIMENSIONS - 300 x 150 x 420 (WxDxH)
Catalogs
GM49
1 Pages
