Mobile crusher S5D

secondarydiesel engine

Main features
Heavy-duty mobile crushing and screening plant with diesel drive and integrated 2-deck screenbox. The screenbox is grease-lubricated with two bearings and an adjustable angle to optimise screening on site.

Technical parameters
Product model: S5D
Drive mode: Diesel
Engine power: 129 kW
Feeding capacity: * t/h
Max input size: 500 mm
Feeding height: 3350 mm
Crushing capacity: * t/h
Overall weight: 29.6 t
Transportation dimension (L×W×H): 14190 mm × 2900 mm × 3200 mm
Working dimension (L×W×H): 14300 mm × 13120 mm × 4400 mm

Specifications

• Product model: S5D
• Drive mode: Diesel
• Engine power: 129 kW
• Feeding capacity: * t/h
• Max input size: 500 mm
• Feeding height: 3350 mm
• Crushing capacity: * t/h
• Overall weight: 29.6 t
• Transportation dimension (L×W×H): 14190 mm × 2900 mm × 3200 mm
• Working dimension (L×W×H): 14300 mm × 13120 mm × 4400 mm

Applications

• Quarrying and aggregates production
• Construction and demolition recycling
• On-site secondary crushing and screening
• Temporary or mobile processing plants
