Jaw crusher S8H

mobilediesel engineprimary

Overview
Hybrid-drive scalper screen S8H equipped with a finger grid, designed for primary heavy-duty screening of complex and abrasive materials.

Main features

• Hybrid drive
• Finger grid for heavy-duty screening
• Adapted for large feed size and continuous operation

Technical parameters

• Product Model: S8H
• Drive mode: Hybrid
• Engine power: 154 kW
• Feeding capacity: 500 t/h
• Input size max: 500 mm (1’8”)
• Feeding height: 3740 mm (12’3”)
• Capacity: 500 t/h
• Overall weight: 37 t (81,571 lbs)

Logistics & dimensions

• Transportation dimension (L×W×H): 15,450 mm × 3,000 mm × 3,400 mm (50’8” × 10’11” × 11’2”)
• Working dimension (L×W×H): 15,480 mm × 14,290 mm × 4,700 mm (50’9” × 46’11” × 15’5”)

Typical applications

• Primary screening in aggregates and mining
• Pre-screening in recycling and demolition processing
