Stationary pipe cutting and beveling machine MPS-T5

motorized

Overview
MPS-T5 is an industrial optical fiber laser pipe cutting machine designed for high-precision cutting of round, square, rectangular and symmetric special-shaped tubes. The model adopts a gear-and-rack drive, pneumatic self-centering chucks and rotary propulsion to ensure consistent positioning and continuous rotation during processing. It supports single-piece lengths up to ≤6500mm and a wide range of wall thicknesses for structural and profile machining.

Key Features

• High Strength Heavy Duty Welded Machine Bed: Welded profile structure with heat treatment and annealing for long-term rigidity and dimensional stability under thermal and dynamic load.
• Linkage Self-Centering Chuck: Front and rear two-pair linkage self-centering chucks with pneumatic automatic clamping for round, square, rectangular, I-beam and symmetric special profiles.
• Integrated CNC Forming Chuck: Fully enclosed chuck protection to prevent dust ingress; hardened wear-resistant moving parts and double roller gripper for stable clamping during rotation and processing.
• Variable-Diameter Wheel Support for Loading: Adjustable support wheels to feed and support long workpieces, reducing vibration and improving straightness and cutting accuracy.
• User-Friendly Operation Interface: Intuitive CNC interface with real-time processing feedback; fully enclosed cutting area with safety doors and observation windows.
• Frog Jumping Cutting: Intermittent (frog jumping) cutting mode reduces idle running time and increases throughput; each perforation point saves approx. 0.3s.

Optional

• Semi-automatic Loading: Pipe length 5500–6100mm; single pipe weight ≤80kg; round pipe Φ20mm–Φ120mm; square pipe 20×20mm–120×120mm.
• Fully Automatic Loading: Pipe length 5500–6000mm; single pipe weight ≤90kg; round pipe Φ20mm–Φ150mm; square pipe 20×20mm–120×120mm; rectangular pipe side 20mm–120mm.
• Slag Blocking: Inner-wall protection to reduce scratches and slag adherence.
• Variable-Diameter Wheel Unloader: Floating unloading device with storage structure for efficient unloading; supports raw material cutting and long workpieces.

Cutting Capacity (visual references present on page)
Reference images show sample cutting results for multiple pipe profiles and sizes used as visual guidance.

Technical Data Sample
For reference only, final values are subject to official technical documents.
Model | Max processable pipe length | Maximum speed | Max operating acceleration | Max load capacity (single) | Tail material length | Range of material wall thickness | Processing capacity
T5 Mini | ≤6500mm | T5mini: 200R/min | 1.0g | 260kg (≤43kg/m) | ≥80mm | ≥0.8mm | H Beam ≤ 8#
T5 | ≤6500mm | T5: 120R/min | 1.0g | 260kg (≤43kg/m) | ≥80mm | ≥0.8mm | H Beam ≤ 20#

Technical Specifications

• Model: MPS-T5
• Machine type: Optical fiber laser pipe/tube cutting machine (gear-and-rack drive, pneumatic clamping chuck, rotating propulsion)
• Supported profiles: Round tube, square tube, rectangular tube, I-beam and symmetric special-shaped tubes
• Max processable pipe length: ≤6500mm
• Maximum rotational speed: T5 Mini 200R/min; T5 120R/min
• Max operating acceleration: 1.0g
• Max load capacity (single): 260kg (≤43kg/m)
• Minimum tail material length: ≥80mm
• Material wall thickness range: ≥0.8mm
• Processing capacity (H Beam): T5 Mini ≤ 8#; T5 ≤ 20#
• Optional modules: Semi-automatic loading, Fully automatic loading, Slag blocking, Variable-diameter wheel unloader
