Water filter Optimum
basketstrainerwire mesh

Water filter - Optimum - Heation AB - basket / strainer / wire mesh
Water filter - Optimum - Heation AB - basket / strainer / wire mesh
Water filter - Optimum - Heation AB - basket / strainer / wire mesh - image - 2
Water filter - Optimum - Heation AB - basket / strainer / wire mesh - image - 3
Add to favorites
Compare this product
Go to the Heation AB website for more information

Characteristics

Designed for
water
Filtration element
strainer, basket, wire mesh, sintered mesh
Filtration method
pressure
Applications
for water treatment, industrial, for aquaculture, process, for HVAC installations, for the food industry, for HVAC, irrigation, coarse pre-filtration, for refrigeration circuits, for cooling towers, for heating systems, for cooling systems, for pipelines, for pipes
Material
stainless steel
Mounting
threaded, flange, thread connection, skid-mounted, on skid
Cleaning
washable, easy cleaning
Fluid specification
process water, for coolant, for potable water
Other characteristics
in-line, Y
Operating pressure

Max.: 16 bar
(232.06 psi)

Min.: 0 bar
(0 psi)

Filtration size

Max.: 5,000 µm

Min.: 10 µm

Flow

Max.: 550 m³/h
(19,423.067 ft³/h)

Min.: 0 m³/h
(0 ft³/h)

Fluid temperature

Max.: 90 °C
(194 °F)

Min.: 0 °C
(32 °F)

Filtration surface

Max.: 7,400 cm²
(1,147 in²)

Min.: 600 cm²
(93 in²)

Description

Description
Optimum is a strainer filter. The housing is manufactured in stainless steel and is available in three constructive shapes: Y, L and O to suit various installation layouts. With a mesh screen as the filtering element, Optimum is suitable as a protection filter in closed-circuit systems and in process water applications with a moderately low quantity of suspended solids.

Design data
Max flow rate [m3/h]: 550
Design pressure [bar]: PN10 (PN16 available on request)
Max temperature [°C]: 90
Salinity [TDS]: <10.000 ppm
pH range: 3 - 9
Design code: PED 68/2014/EU

Material
Filter housing: Stainless steel AISI 304 / AISI 316
Gasket: EPDM*
Drain/vent valve: Nickel-plated brass / AISI 316
Pressure gauges: Stainless steel AISI 304 / AISI 316
Surface finish: Micro shot peening and passivation

Certifications
* Certified for the following European drinking water regulations: UBA, DVGW-standard W-270, WRAS and ACS.

Characteristics / technical specifications
  • Model name: Optimum
  • Construction shapes available: Y, L, O
  • Filtering element: Mesh screen
  • Application: Protection filter in closed-circuit systems and process water applications with moderately low suspended solids
  • Max flow rate: 550 m3/h
  • Design pressure: PN10 (PN16 available on request)
  • Max temperature: 90 °C
  • Salinity (TDS): <10.000 ppm
  • pH range: 3 - 9
  • Design code: PED 68/2014/EU
  • Filter housing material: Stainless steel AISI 304 / AISI 316
  • Gasket: EPDM (certified per listed drinking water regulations)
  • Drain/vent valve: Nickel-plated brass / AISI 316
  • Pressure gauges: Stainless steel AISI 304 / AISI 316
  • Surface finish: Micro shot peening and passivation
