Optical alignment system megaline Logik8 Panelmeasurementwireless
Add to favorites
Compare this product
Characteristics
- Technology
- optical
- Applications
- measurement
- Other characteristics
- wireless
Description
Short description
Features
Standard accessories
Technical specifications
- Space-saving wall-mounted CCD wheel alignment system with two metal panels that act as supports and charging stations for 4 CCD sensors and a 10" toughpad tablet.
Features
- Two independent wall panels can be positioned anywhere in the workshop to maximize installation flexibility.
- Panels include trays for the tablet, grips and accessories, plus supports for wheel clamps, a steering wheel brake and a brake pedal lock.
- 10" rubberized toughpad with magnetic back and Wi‑Fi connectivity allows the operator to run alignment software from any workshop position; suitable for use under the vehicle.
- Sensors and toughpad recharge via cable when stored on the panels — no battery disassembly required.
- Alignment software runs on Windows 10 and includes a vehicle database.
Standard accessories
- 2 metal wall panels
- 10" toughpad tablet
- 4 CCD car sensors
- 4 wheel clamps (12"–24") with elastic protective tape
- Grip set: 48 mm and 80 mm metallic grips
- 1 steering wheel brake and 1 brake pedal lock
- Alignment software and vehicle database
Technical specifications
- System type: Wall-mounted CCD wheel alignment panels
- Number of panels: 2 metal wall panels serving as support and charging station
- Tablet: 10" rubberized toughpad, Wi‑Fi enabled, rechargeable on panel
- Operating system: Windows 10
- Sensors: 4 CCD sensors for passenger cars
- Wheel clamps: 4 clamps for 12"–24" wheels, with elastic protective tape
- Grip set: 48 mm and 80 mm metallic grips
- Accessories: Steering wheel brake and brake pedal lock included
- Charging: Cable recharge when stored on panels (no battery disassembly)
- Installation: Panels can be positioned independently anywhere in the workshop
