Cylindrical anti-vibration mount VEsteelstainless steelgalvanised steel
Add to favorites
Compare this product
Characteristics
- Configuration
- cylindrical
- Material
- steel, stainless steel, galvanised steel, elastomer
- Applications
- for pipework, for air conditioning, for buildings
- Other characteristics
- metal cushion damper, ring, threaded, spring damper, vibration damper
Description
Product description
VE isolators consist of a cylindrical stainless steel spring, a galvanised body, an elastomer noise reduction guide and steel rings or studs depending on the model. The VE112 series includes a steel cushion inside the spring.
Construction
VE112 feature
The VE112 series has a metal cushion inserted inside the spring to modify stiffness and damping behaviour.
Specifications
These isolators have natural frequencies between 3.5 and 6 Hz and are designed for suspending false ceilings, HVAC equipment and pipework, providing significant reduction of structure-borne noise in buildings.
IGS and 3D files
Applications
Technical specifications
VE isolators consist of a cylindrical stainless steel spring, a galvanised body, an elastomer noise reduction guide and steel rings or studs depending on the model. The VE112 series includes a steel cushion inside the spring.
Construction
- Cylindrical stainless steel spring
- Galvanised sheet metal body
- Elastomer acoustic guide
- Steel rings or studs depending on model
VE112 feature
The VE112 series has a metal cushion inserted inside the spring to modify stiffness and damping behaviour.
Specifications
These isolators have natural frequencies between 3.5 and 6 Hz and are designed for suspending false ceilings, HVAC equipment and pipework, providing significant reduction of structure-borne noise in buildings.
IGS and 3D files
- VE111-XX (IGES / 3D file available)
Applications
- False ceilings
- Piping
- Air conditioning units and HVAC equipment
Technical specifications
- Models: VE101, VE111, VE112, VE113
- Materials: stainless steel spring, galvanised body, elastomer guide
- Natural frequency: 3.5 – 6 Hz
- Typical use: traction suspension for ceilings, HVAC and pipework
- VE112: metal cushion inside the spring
- Fixing: pin or two threaded rods depending on model
