Chain sprocket wheel BISstraight-toothedpolyamidewith ball bearing
Add to favorites
Compare this product
Characteristics
- Type
- chain
- Teeth
- straight-toothed
- Material
- polyamide
- Other characteristics
- with ball bearing
- Diameter
Max.: 98 mm
(4 in)Min.: 43 mm
(2 in)
Description
Imao’s sprockets are available from a wide variety of materials and sizes.
BIS: Plastic Idle Sprockets
・ Light-duty
・ Stable rotation with moulded-in ball bearing
・ Glass-fiber reinforced polyamide body for high wear resistance
・ Applicable to chain No. 25, 35, 40, 50, 60, 80
・ For 10mm and 15mm diameter spindle
Use with PID Idler Pins.
Materials:
Sprocket body: Glass-fiber reinforced polyamide plastic, Black color
Bearing: Steel
Datasheet: https://www.imao.co.jp/files/on-cat/pdf/en/bis-e.pdf
