Locking device couplings
SHAFT COUPLING CLAMP WITH SAFETY LOCK HEAVY DUTY SHAFT COUPLING CLAMP For frequent changeover of machinery or fixture. Shaft Coupling ...
Torque: 824.9 Nm
Rotational speed: 0 rpm - 25,400 rpm
Curved Jaw Style (GS Series) Zero backlash in a 3 piece design Aluminum and steel hubs Clamping and locking device hubs available Four different types of urethane elastomers available
Torque: 29 Nm - 160,000 Nm
Self-centering, external shaft locking device Exceptional concentricity Suitable & recommended for hollow shafts Axial hub position fixed during clamping Metric 14mm to 240mm (larger ...
Torque: 230 Nm - 766,800 Nm
These shaft locking devices manufactured by Lovejoy is a medium high torque, internal shaft locking device with no backlash. Its compact framework is easy to install, ...
Torque: 196 Nm - 173,000 Nm
... popular multipurpose type Standard (Inch sizes available) Electroless Nickel-Plated Stainless Features Multipurpose locking devices easy to install and remove. Extensive range of sizes and compatible ...
Torque: 382 Nm - 429,000 Nm
High torque transmission capacity type Standard Electroless Nickel-Plated Features Capable of transmitting 1.5 to 3 times the AS Series rated torque capacity. With its centering feature, eliminates the hassle of machining on hubs ...
Torque: 5 Nm - 9,900 Nm
... Contact Pressure type Locking Principles and Features Designed to suit a wide range of shaft tolerances (except for KP models). Standard models can accommodate plus shaft tolerances of servomotors, etc. Excellent ...
Torque: 5,000 Nm
Rotational speed: 2,500 rpm - 10,000 rpm
This range of torsional couplings solve torsional vibration problems typical of those found in diesel engine applications. The torsional coupling dampens torsional vibrations and tunes the system to have ...
Torque: 30 Nm - 450 Nm
Rotational speed: 10,000 rpm
... Metal Bellows Couplings provide the ideal complement to Magtrol’s TM/TMB/TMHS/TS In-Line Torque Transducers and Sensors, when these are to be mounted in a drive train. The torque transmission element consists of a metal ...
Torque: 355 Nm - 512,635 Nm
Locking Assembly RfN 7003 Two piece design with slit and single taper and without flange can be completely recessed within a component’s hub. Axial position of component not fixed and may move during installation. Characteristics Self-centering, ...
Torque: 530 Nm - 63,903 Nm
Locking Assembly RfN 7004 Extended version of the Locking Assembly RfN 7003 allowing for use with smaller hub diameters due to the reduced shaft and hub pressures. Characteristics Is the extended ...
Torque: 649 Nm - 1,760,000 Nm
Locking Assembly RfN 7005 Three piece self-centering design for heavy duty torques. Characteristics Three piece, self-centering, slitted locking assemblies for highest bending moments and torques. ...
Torque: 743 Nm - 155,248 Nm
... ensures resistance from any vibration, or torsion content reversal. It may be utilized either as a locking assembly, clamping component, or as a locking tool. The manufacturer's products ...
Torque: 3 Nm - 1,652,075 Nm
self locking units, made of hardened and tempered steel, allow machine parts with round bore to be locked on shafts. 14 types available, self-centering or not.
Torque: 300 Nm - 190,000 Nm
The Locking Assembly MAV 4071 L is built with a high capacitative torque unit with a self-releasing and self-centering capability. It also has fixed axial fixation of hub in the event of tightening the device ...
Torque: 3 Nm - 3,060 Nm
MAV's 3003 Locking Assemblies are low-capacity, non-self-centering and non-self-locking components. These apparatuses sport minimized axial and radial dimensions, shaft surface finishes and hub bore (Ra) ...
Torque: 40 Nm - 1,080 Nm
The Locking assembly MAV 3505 is specifically made having a low torque capacity and a low contact pressures. This does not offer self-locking and self-centering features. Its shaft-hub bore max surface ...
Torque: 270 Nm - 120,003 Nm
Rotational speed: 0 rpm - 20,000 rpm
... solution Correct material selection to prevent permanent shrink of hub to shaft Lightest weight locking device/hub combination selected Hub and locking device balanced ...
Torque: 1 Nm
Coupling Avant 200 och 300-700---AC10A/B Couplings that fit all types of equipment and machinery. The couplings are cut from high quality steel to provide the best possible life span.
