ISO threading die

roundrolling

Overview
We manufacture circular thread rolling dies for use on thread rolling machines. Produced to customer specifications, our dies suit a wide range of machine models and thread standards and are manufactured to international quality standards.

Use / Application
These rolling dies form external threads by cold forming on thread rolling machines. They are supplied in matched sets (two- or three-piece) designed for specific machine types, shaft diameters and thread profiles.

Materials & Set Composition

• Set sizes: 2-piece and 3-piece sets
• Materials: D2, D3 and M2 tool steels

Supported Thread Forms / Standards

• ISO Metric
• DIN
• Whitworth
• American (UNC/UNF)
• Trapezoidal
• Acme
• Other custom or standard thread forms on request

Available Options

• Thread type: Metric, UNC/UNF, BSW, Acme, two-start, three-start, trapezoidal, others
• Delivery timing: Immediately, within a week, within 15 days, within a month, other

Specifiable Parameters (customer to provide)

• Thread roll width
• Thread roll diameter
• Bore diameter
• Required thread form and pitch
• Expected price or budget

Notes
Dies can be produced to match any thread rolling machine model and to customer drawings or samples. Contact us with machine type and required dimensions for a precise quotation.

Technical specifications

• Product: Circular thread rolling dies
• Application: Forming external threads on thread rolling machines
• Set composition: Supplied as 2-piece or 3-piece sets
• Materials: Tool steels D2, D3, M2
• Supported thread standards: ISO Metric, DIN, Whitworth, American (UNC/UNF), trapezoidal, Acme and others
• Customization: Manufactured to customer specifications (width, diameter, bore, thread type)
• Quality: Produced to international quality standards
