Max opening -
900 mm
Height -
2510 mm
Width -
1450 mm
Jaw width -
450 mm
Oil delivery -
140 ÷ 220 l/min
Maximum working pressure -
350 bars
Maximum clamping force at tip -
80 tons
Maximum clamping force at shears -
265 tons
Shear length -
240 mm
Max cutting diameter -
45 mm
Min. closure time -
3 s**
Min. opening time -
1,5 s
Hydraulic connections -
3/4”
Maximum rotation flow -
25 l/min
Maximum rotation pressure -
110 bars
Hydraulic connections for rotation -
1/2”
Mounting bracket compatibility -
HP 3000 ÷ HP 4000
Type of carrier -
- Wheeled excavator
- Tracked excavator
