Excavator weight -
30 ÷ 55 tons
Attachment operating weight* -
3600 Kg
Max opening -
1050 mm
Height -
2800 mm
Width -
1480 mm
Jaw width -
520 mm
Oil delivery -
150 ÷ 250 l/min
Maximum working pressure -
350 bars
Maximum clamping force at tip -
105 tons
Maximum clamping force at shears -
355 tons
Shear length -
240 mm
Max cutting diameter -
50 mm
Min. closure time -
2 s
Min. opening time -
2 s
Hydraulic connections -
1”
Maximum rotation flow -
30 l/min
Maximum rotation pressure -
110 bars
Hydraulic connections for rotation -
1/2”
Mounting bracket compatibility -
HP 7000 - HP 9000
Type of carrier -
- Tracked excavator
