Excavator weight -
25 ÷ 45 tons
Attachment operating weight* -
2950 Kg
Max opening -
960 mm
Height -
2645 mm
Width -
1470 mm
Jaw width -
490 mm
Oil delivery -
150 ÷ 250 l/min
Maximum working pressure -
350 bars
Maximum clamping force at tip -
95 tons
Maximum clamping force at shears -
325 tons
Shear length -
240 mm
Max cutting diameter -
50 mm
Min. closure time -
2 s
Min. opening time -
2 s
Hydraulic connections -
1”
Maximum rotation flow -
30 l/min
Maximum rotation pressure -
110 bars
Hydraulic connections for rotation -
1/2”
Mounting bracket compatibility -
HP 5000
Type of carrier -
- Tracked excavator
