Panel-mount weight display FL-TM

ruggedRS-232USB

Overview
Display for tensile and/or compressive force sensors. Reversible backlit screen for upright or inverted mounting. Metal housing for use in harsh environments. Internal memory for 500 measurement points. Units available: N, kN, kg, oz, lb.

Main functions

• Peak-hold and track modes for instantaneous or peak value display
• Programmable tolerance zone with acoustic and visual alarm on threshold exceedance
• Transfer of memory content to PC via USB (software optional)
• RS-232 serial data interface (permits connection only to a printer)

Selectable rated loads

• 5 N
• 10 N
• 25 N
• 50 N
• 100 N
• 250 N
• 500 N
• 1 kN
• 2.5 kN
• 5 kN
• 10 kN
• 20 kN
• 50 kN

Specifications / technical data

• Measurement frequency: 1000 Hz
• Transfer rate to PC: approx. 25 Hz
• Measurement accuracy: 0.2 % of full scale (FS)
• Maximum resolution: 2500 d
• Overload protection: 120 % of FS
• Analog output proportional to load: -2 to +2 V
• Dimensions (L×D×H): 175×75×30 mm
• Power supply: internal rechargeable battery
• Battery life: up to 10 h without backlight
• Charging time: approx. 8 h
• Net weight: approx. 0.5 kg
• Internal memory: 500 measurement points
• Metal housing for operation in harsh conditions
• Options: USB transfer software available; calibration certificate (COFRAC or equivalent) available as an option
