Foodstuff hose CRYSTAL CLEAR 55
TPEFDAfor the pharmaceutical industry

Foodstuff hose - CRYSTAL CLEAR 55 - IPL SPA - TPE / FDA / for the pharmaceutical industry
Foodstuff hose - CRYSTAL CLEAR 55 - IPL SPA - TPE / FDA / for the pharmaceutical industry
Foodstuff hose - CRYSTAL CLEAR 55 - IPL SPA - TPE / FDA / for the pharmaceutical industry - image - 2
Add to favorites
Compare this product

Characteristics

Use
foodstuff
Material
TPE
Applications
FDA, for the pharmaceutical industry, process, sanitary, peristaltic pump, laboratory
Other characteristics
abrasion-resistant, chemical-resistant, standard, translucent, extruded
Inner diameter

Max.: 12.7 mm
(0.5 in)

Min.: 3.2 mm
(0.126 in)

Outer diameter

Max.: 19.1 mm
(0.752 in)

Min.: 6.4 mm
(0.252 in)

Pressure

Max.: 1.2 bar
(17.405 psi)

Min.: 0.5 bar
(7.252 psi)

Temperature

Max.: 80 °C
(176 °F)

Min.: -20 °C
(-4 °F)

Delivered length

7.5 m, 15.2 m
(24'07" , 49'10" )

Description

Hygienic TPE pharma-grade tubing for peristaltic pumps specifically engineered for applications within food, pharmaceutical, biotech and cosmetic industries. Tube features: the extruded, low porosity TPE tube reduces permeation problems. Highly neutral in taste and odor, it preserves the organoleptic properties of the medium. Good chemical resistance to acids and alkaline solutions and good impermeability. Versatile rubber resistant also to alcools with max. 50% concentration. Much more impermeable than silicone elastomers. Superior working life on peristaltic pumps when compared with similar tubings of the competition (average working life >190 hours when tested on a 3 lobes pump with 600 turning/minute) and minimal spallation on pump heads. Standards: ISO 10993-5 (Non cytotoxic) ISO10993-4 (Non haemolytic, direct and indirect methods) USP CLASS VI USP Physicochemical Tests-plastics EU Regulation n° 10/2011 (classes A, B, C, D1 and dry food) FDA regulations (Title 21 CFR 177.2600 classes D, E)
