Measurement monitoring device UMG 512-PRO

power qualitydigitalmeasuring device

Class A power quality analyzer The UMG 512-PRO is a class A certified power quality analyzer per IEC 61000-4-30. Power quality parameters such as harmonics up to the 63rd harmonic, flicker, short term interruptions, etc., are measured with class A. Certified measurement processes with high accuracy of measurement are applied to check the power quality according to EN 50160 at the PCC as well as in the internal supply network according to EN 61000-2-4. Class A Measuring devices in class A are certified to the IEC 61000-4-30 standard. It provides detailed specifications that a mains analyzer must meet so that the results can also be consulted in case of disputes. The standard defines the necessary parameters, suitable measurement methods, accuracy and bandwidths. This makes it possible to easily reproduce and compare results. Power quality Reliable operation of modern plants and systems always demands a high degree of supply reliability and good power quality. UMG measuring devices reliably record, analyse and document all interferences such as harmonics, unbalance, transients, voltage dips, voltage swells, flickers, phase shifts and reactive power. BACNET BACnet is one of the most important communication standards for building technology, mainly due to its compatibility with the most diverse hardware and its uniform communication with devices from various manufacturers. As soon as a UMG measuring device has received its BACnet ID and is integrated into the network, the system recognises it and displays it in the browser. This makes configuration very easy.
