Axial piston pump IP60-200

waterelectricstationary

When you need high pressure and high gpm flow rates for your cutting or specialty application this is the answer. Visit our Case Study Library to learn how innovative users use pump technology for Burst Testing, Nuclear Reactor Peening, Robotic Aircraft Engine Parts Cleaning and Textile Trimming • Max rated orifice size .028 in (.71 mm) • Single piston, dual plunger, reciprocating pump CONSTRUCTION • Heavy-gauge sheet metal covers • Rugged all-steel welded framework • Hinged cover & quick-remove access covers CONTROLS • UL Certified electrical panel • Safety shutdown systems • Automatic safety pressure bleed-down valve • Optional advanced control package INTENSIFIER PUMP • Double, 2 quarts (1.9 liters) attenuator • Single piston, dual plunger, reciprocating pump • Rated Pressure: 60,000 psi (4100 bar) • UHP flow rate: 4.0 gpm (15.2 lpm) • Max rated orifice size .028 in (.71 mm) ELECTRIC MOTOR • Motor output: 200 hp (149 kw) • TEFC NEMA premium efficiency motor • Full load amps @ 460vac: (60Hz) 240 • Full load amps @ 380vac: (50Hz) 288 • WATER/ENVIRONMENT • Low-pressure water supply requirement 8–12 gpm (30 – 45 lpm) @ 60 psi (4.1 bar) min. • Max temp 70ºF (21ºC) • Ambient temperature: 50-100ºF (10-37º C) HYDRAULICS • Axial piston, variable displacement, pressure-compensated hydraulic pump • Thermostatically-controlled cooling loop • Hydraulic accumulator prolongs component life and improves output quality WARRANTY • 1-year or 2,000-hour pump warranty • 2-year or 4,000-hour hydraulic circuit warranty • Extended warranties available • Technical service and free lifetime Factory Training • Waterjet Best Practices and more are available in our Resource Center
