Barebone PC B420UADN1

expansionboxembedded

Fanless Compact Box PC with Intel® N-series SoC Processors Features - Powered by Intel® N97 SoC Processors (formerly Alder Lake) - High-Performance Memory: Supports DDR5 SO-DIMM - 4K Display: Supports DP Alt Mode - Storage and Expansion: 1 x M.2 M-Key, and 1 x M.2 E-Key - Enhanced Security: Intel® PTT with TPM 2.0 (Optional dTPM) - Dual 2.5GbE Ports for Reliable and High-Speed Networking Connections Specifications MB FORM FACTOR: NUC CPU: Onboard Intel® Processor N97 (Formerly Alder Lake-N, TDP 12W) CHIPSET: Intel® SoC MEMORY: 1 x DDR5 4800MHz, Single Channel SO-DIMM, up to 32GB BIOS: UEFI WAKE ON LAN: Yes WATCHDOG TIMER: 255 Levels SECURITY: TPM2.0 (dTPM, Optional) Intel® PTT (Integrated fTPM) RTC BATTERY: Lithium Battery OS SUPPORT: Windows® 11 (64bit) Windows® 10 (64bit) Linux POWER POWER REQUIREMENT: DC-in 12~19V 60W Adapter: AC90~240V, DC12V/5.0A POWER ON MODE: AT / ATX (Default) Mode DISPLAY GPU: Intel® UHD Graphics Type-C DP: 2 x Type C DP1.4 (Max Resolution: 4096 x 2160@60Hz) DP: 1 x DP1.4 (Max Resolution: 4096 x 2160@60Hz) HDMI®: 1 x HDMI 2.0 (Max Resolution: 4096 x 2160@60Hz) MULTIPLE DISPLAY: Support 3 Displays AUDIO CODEC: Realtek Codec LAN ETHERNET: 2 x RJ45 for Intel® I226-V 2.5GbE SYSTEM I/O REAR PANEL I/O: 2 x RJ45 1 x HDMI 2.0 1 x DP 1.4 2 x USB 3.2 Gen 2 1 x DC-in (Lockable) 2 x WIFI Antenna Holes (Optional) 1 x GND Hold FRONT PANEL I/O: 1 x Power Button 2 x USB 3.2 Type C support DP ALT mode 1 x Combo Audio (Line out & Mic) 1 x RS-232/422/485 EXPANSION M.2: 1 x M-Key 2260/2280 (PCIe 3.0 x2/SATA III) Support NVMe 1 x E-Key 2230 (USB 2.0/PCIe 3.0 x1) Support CNVio MECHANICAL MOUNTING: Wall + VESA mount DIMENSIONS (W x D x H): 129.0 (W) x 109.4 (D) x 34.0 (H) mm NET WEIGHT: 0.56 KG ENVIRONMENT & CERTIFICATION OPERATING TEMPERATURE: -20°C ~ 60°C (-4°F ~ 140°F) CERTIFICATION: CE/FCC Class A LVD ESG DECLARATION: China RoHS CMRT Report TSCA Declaration WEEE REACH Packing List PART NUMBER: DESCRIPTION: QTY B420UADN1: B420UADN1 Barebone: 1 HCS310MWM01B-2F: Wall+VESA mount Kit: 1 LCSCHBJC3XX-F: Screw Pack: 1 L01AS052-F: Lockable Adapter 12V/5A 60W: 1 Change according to shipping area: Power Cord (Region Specific): 1 Note: All specifications are subject to change without notice. Technical Specifications: - Form Factor: NUC - Processor: Intel® N97 (Alder Lake-N, TDP 12W) - Chipset: Intel® SoC - Memory: 1 x DDR5 4800MHz SO-DIMM, up to 32GB - BIOS: UEFI - Wake on LAN: Yes - Watchdog Timer: 255 Levels - Security: TPM2.0 (dTPM, Optional), Intel® PTT (Integrated fTPM) - RTC Battery: Lithium Battery - OS Support: Windows® 11/10 (64bit), Linux - Power Requirement: DC-in 12~19V, 60W Adapter: AC90~240V, DC12V/5.0A - Power On Mode: AT / ATX (Default) - GPU: Intel® UHD Graphics - Display Outputs: 2 x Type C DP1.4, 1 x DP1.4, 1 x HDMI 2.0 (all max 4096 x 2160@60Hz) - Multiple Display: Support 3 Displays - Audio: Realtek Codec - Ethernet: 2 x RJ45 for Intel® I226-V 2.5GbE - Rear Panel I/O: 2 x RJ45, 1 x HDMI 2.0, 1 x DP 1.4, 2 x USB 3.2 Gen 2, 1 x DC-in (Lockable), 2 x WIFI Antenna Holes (Optional), 1 x GND Hold - Front Panel I/O: 1 x Power Button, 2 x USB 3.2 Type C (DP ALT mode), 1 x Combo Audio (Line out & Mic), 1 x RS-232/422/485 - Expansion: 1 x M-Key 2260/2280 (PCIe 3.0 x2/SATA III) Support NVMe, 1 x E-Key 2230 (USB 2.0/PCIe 3.0 x1) Support CNVio - Mounting: Wall + VESA mount - Dimensions: 129.0 (W) x 109.4 (D) x 34.0 (H) mm - Net Weight: 0.56 KG - Operating Temperature: -20°C ~ 60°C (-4°F ~ 140°F) - Certification: CE/FCC Class A, LVD - ESG Declaration: China RoHS, CMRT Report, TSCA Declaration, WEEE, REACH
