Fixed scissor lift platform SJG80.0-1.0

hydraulicfor aeronautics

This heavy-duty hydraulic synchronous scissor lift platform is designed for loading large machinery and vehicles, with an 80-ton capacity and 1-meter lifting height. It enables smooth transfer to flatbed trailers and stable vehicle support. Controlled via console and remote, it uses sensors, proportional valves, and a PLC for precise synchronous lifting. Measuring 12,000 × 600 × 1,000 mm, it features anti-corrosion coating, side supports, and drainage with automatic water pump. Ideal for heavy machinery and special vehicle shipping. - Model: SJG80.0-1.0 - Platform Dimensions: 1200*10000mm - Loading Capacity: 80,000KG - Travel Height: 1000mm - Motor Power: 22kW - Scissor Structure: Three-span Single-layer Note: The above parameters are for reference only, all products can be customized 1. Ultra-High Load Capacity (80 Tons) The platform is engineered to handle the full weight of large vehicles and heavy machinery, providing reliable lifting performance for complete vehicle transfer and dispatch operations. 2. Synchronous Lifting System The platform uses a combination of sensors, proportional valves, and a PLC control system to achieve precise synchronization between multiple lifting points, ensuring smooth and stable vertical movement under heavy loads. 3. Dual Control Modes Operators can control the system through both a fixed control console and a wireless remote, offering flexible operation while maintaining safety during loading and unloading procedures. 4. Smooth Vehicle Transfer The platform aligns seamlessly with flatbed trailers, enabling a stable transition of vehicles onto the trailer and improving outbound logistics efficiency. 5. Corrosion-Resistant Surface Coating The steel structure is treated with a high-performance anti-corrosion system using an epoxy zinc-rich primer and a protective topcoat. The total dry film thickness exceeds 200μm, offering excellent resistance to weather and harsh industrial environments. Standard color: medium gray. 6. Integrated Safety and Accessibility Features A stairway is integrated at the platform end, allowing safe and easy access for operators. The design considers ergonomic and safety requirements during use and maintenance. 7. Automatic Drainage System The pit is equipped with a water pump and liquid level sensor. When the water level exceeds the preset threshold, the system automatically activates drainage to ensure safe operation even in wet environments.
