Thickness measuring device MESSBOI 40 B LC / LC-MID

speedlengthscanning

Stationary, belt length measuring device for winding materials up to max. 40 mm outer Ø with optional conformity assessment (formerly calibration). Ideal for measuring a wide variety of winding materials such as round and flat material in the form of cables, pipes, hoses and ropes This length measuring device is used for round and flat material such as cables, pipes, hoses, ropes of all kind. It is perfectly suited for high measurement precision and low measurement tolerances. The chassis consists of a stainless steel casing in which above all the sensitive components are well protected against outer influences. The scanning of the material to be measured is ensured by two measuring tape units running against each other. The top tape unit is liftable by means of a knee lever and due to its coordinated own weight adapts itself to the thickness of the material to be measured. For registration the length, the bottom measuring unit is provided with a rotary pulse encoder. Basic equipment One set of inlet and outlet rollers with adjustable width Measuring tape with manual column-type measuring wheel adjustment Flange for a second rotary pulse encoder, provided for in the stainless steel casing Preselection counter and rotary pulse encoder integrated in the stainless steel casing A preselection counter LC MID with two potential-free electric contacts for controlling the fast motion / inching function of an adjustable winding drive. Supervision of the calibrating speed with a luminous indicator Supplementary equipment Tripod stand for floor mounting (Height adjustable 1320 - 1620 mm) or stand for table mounting Holding arm with inlet and outlet roller cage
