Diameter measuring device MESSBOI 40 BAE

lengthprofilescanning

Stationary, mechanical length measuring device for winding materials up to max. 40 mm outer Ø with optional conformity assessment (formerly calibration). Convincing due to the modular assembly and stable base body with guide rollers Measuring unit for winding goods up to an outer diameter of 40 mm with mechanical counter. Depending on the application we offer various versions to customer specification. These measuring units consist of a solid carcass equipped with guide rollers to which the measuring device is mounted. Measuring scanning by means of measuring wheel. Calibration approval for sheathed round cables with additional inlet and outlet. If requested, also available with stainless steel-counter roller for the measuring of steel ropes.Conformity certification of the length measuring device with additional inlet and outlet rollers for coated round cables is approved by German Authorities for a period of two years and valid for all EU/EEA member states. Attention: Conformity assessment / MID (formerly first calibration) is only approved for usage in direct sales! Basic equipment One set of inlet and outlet rollers of adjustable height and centrally adjustable width The length is measured by a measuring wheel Adding mechanical counter with reset button Supplementary equipment Alu-profile with mounting plates for roller caes, measuring device, housing for the counter and lever shear Inlet and outlet roller cages Conformity assessment / MID (formerly first calibration)
