Diameter measuring device MESSBOI 80 LC / LC-MID

speedlengthscanning

Stationary, digital length measuring device for winding materials up to max. 80 mm outer Ø with optional conformity assessment (formerly calibration). Convincing due to the automatic and tamper-proof data storage of all measurements This measuring device consists of a solid base body with guiding rollers to which the measuring device is mounted. The scanning of the material to be measured is ensured by a measuring wheel. Basic equipment A casing fitted to the length measuring device for the counter The length is measured by a measuring wheel One set of inlet and outlet rollers of adjustable height and centrally adjustable width A rotary pulse encoder with connection cable A preselection counter LC MID with interface RS 232 with two potential-free electric contacts for controlling the fast motion/inching function of an adjustable winding drive or a luminous indicator. Supervision of the calibration speed with luminous indicator. Supplementary equipment Diameter recognition mounted on the MESSBOI 80 Conformity assessment / MID (formerly first calibration)
