Diameter measuring device MESSBOI 40 LC / LC-MID

speedlengthangle

Stationary, digital length measuring device for winding materials up to max. 40 mm outer Ø with optional conformity assessment (formerly calibration). Convincing due to the automatic and tamper-proof data storage of all measurements Length measuring device with digital counter. Depending on the application we offer various versions to customer specification. This measuring device consists of a solid base body with guiding rollers to which the measuring device is mounted. The scanning of the material to be measured is ensured by a measuring wheel. Conformity assessment / MID with additional inlet and outlet rollers carried out by National Metrology institute of Germany (PtB) valid for a period of two years for all European member states. . Basic equipment A casing fitted to the length measuring device for the counter The length is measured by a measuring wheel One set of inlet and outlet rollers of adjustable height and centrally adjustable width A rotary pulse encoder with two channels A+B, 24VDC and connection cable A preselection counter LC MID with interface RS 232 with two potential-free electric contacts for controlling the fast motion / inching function of an adjustable winding drive or a luminous indicator. Supervision of the calibration speed with luminous indicator Supplementary equipment Angle drive for easy operation of the central adjustment of vertical guides on MESSBOI 40 Cable end detection Sensor for measuring the cable diameter for automatic traversing and for switching off the winding drive at the cable end Inlet and outlet roller cages Conformity assessment / MID (formerly first calibration) Label printer Barcodescanner
