Portable coordinate measuring machine XM series

manualfor large partsfor small parts

Portable, Benchtop CMM High-accuracy measurement over a large area; on or off the system • High-accuracy 3D measurement with a handheld probe • Large-area measurement with a maximum measurement size of 2 m (6.6') • Selectable measurement styles The XM Series is a handheld coordinate measuring machine (CMM) that lets anyone easily measure 3D/GD&T features. The system is portable and shop-floor ready, so measurements can be taken in any location. The unit also automatically records measurement data and creates detailed inspection reports. The images showcases our latest XM-5000 model which allows high-accuracy measurement for palm-sized parts to large applications. Targets can be approached from any angle, allowing for intuitive measurement. The measurement results displayed on the monitor are easy to understand and include images. Large-Area Measurement With a Maximum Measurement Size of 2 m (6.6') The measurement space is 66 times larger than that of conventional models. Everything from palm-sized parts to large parts can be measured. Selectable Measurement Styles The measuring head can be installed not only on the stage but also on a dedicated mount or tripod. This new-concept coordinate measuring machine can be placed anywhere.
