Through-beam photoelectric sensor PX series
cylindricalLEDrugged

through-beam photoelectric sensor
through-beam photoelectric sensor
Add to favorites
Compare this product


Characteristics

Sensing mode
through-beam
Housing
cylindrical
Type of beam
LED
Other characteristics
rugged, high-power, IP69K
Maximum range

Min.: 400 mm (15.7 in)

Max.: 40,000 mm (131.2 in)

Description

FEATURES The new PX Series heavy-duty industrial photoelectric sensors. Rugged industrial sensors designed for use in harsh environments. 7 Sensor Head Variations High-power MEGA mode Industry's First High Resolution Display FACT 1 Backfilled structure The case is completely backfilled under vacuum with transparent epoxy resin. This ensures maximum adhesion with the cable and lens, and prohibits liquid entry. FACT 2 Stainless-steel housing is approx. 1.9 mm* thick The thick walls of the sensor permit higher levels of installation torque, preventing release due to vibration or shock. * PX-H72(G) only. The cases of other models are 1.5 mm in thickness. FACT 3 Glass lens The tough, scratch-resistant, optical glass lens can be used in the harshest environments. FACT 4 Ultra high-intensity LED Incredible power by combining infrared or 4-element red LED with an optical quality glass lens. FACT 5 Plastic inner sleeve The plastic inner sleeve has low water absorbing properties and excellent oil-resistance. It prevents water or oil from penetrating the case.
