Linear position sensors

Measuring rate: 200 Hz

• GMR magnetoresistive sensors. • PNP or NPN logic output. • No problems in case of vibrations. • Cable output or M8 connector. • 100% traceability. • Direct application in "C" slot. • Slot adapters on request. • ...

Measuring rate: 500 Hz - 200,000 Hz

• Reed sensors or GMR magnetoresistive sensors. • PNP or NPN logic output for magnetoresistive sensors. • No problems in case of vibrations. • Cable output or M8 connector. • 100% ...

Measuring rate: 1 kHz

•No problems in case of vibrations. •Cable or M8 connector output. •100% traceability. •Standard T-slot inline mounting. •Optional K-SL slot adaptors. •Optional 2.5m, 5m and 10m cable extensions.

Measuring range: 2,000 mm
Supply voltage: 15 V - 30 V
Ambient temperature: -25 °C - 70 °C

Rectangular, aluminium / plastic Versatile mounting possibilities Measuring range displayed via LED Immune to electromagnetic interference Extremely short blind zones Process value ...

Measuring range: 2,000 mm
Supply voltage: 15 V - 30 V
Ambient temperature: -25 °C - 70 °C

Rectangular, aluminium / plastic Versatile mounting possibilities Measuring range displayed via LED Immune to electromagnetic interference Extremely short blind zones Resolution, 16-bit ...

Measuring range: 100 mm
Supply voltage: 15 V - 30 V
Ambient temperature: -25 °C - 70 °C

Rectangular, plastic Many mounting possibilities Positioning element P1-Li-QR14/Q17L, mounting aids M1.1-Q17L and M1.2-Q17L included in delivery LED indicates measuring range Immune to electromagnetic ...

Measuring range: 100 mm - 1,500 mm

The P60 and P96 Series are composed of draw wire sensors for general purposes. They come with many options like different kinds of analog outputs and measuring ranges to cater virtually all applications. The measuring ...

Measuring range: 50 mm - 250 mm
Linearity: 0.2 % - 0.3 %
Ambient temperature: -20 °C - 80 °C

The draw wire sensors of the MPM Series are the preferred choice in applications which are characterized by fast movements, short displacements and limited space. This is achieved using miniaturized components combined ...

Measuring range: 100 mm - 1,000 mm
Linearity: 0.1 % - 0.5 %
Ambient temperature: -20 °C - 80 °C

The MP/MPW Draw-Wire Sensors, manufactured by Micro-Epsilon, are generally designed for usage involving industrial and mobile applications. Furthermore, this compact draw-wire displacement sensor, suitable ...

... as required. The sensors can be used to easily replace currently installed sensors and used without IO-Link thanks to their backward compatibility he all-rounder for position and process ...

Measuring range: 1.8, 2 mm

Pressure-resistant sensors •Pressure-resistant up to 500 bar •Metal sensing face for heavy duty •High bursting pressure •Housing design to industrial standard •Lifespan of more than 10 million pressure cycles

Cylinder sensors - Use on T-slot cylinders •Easy fit 'drop from the top' into a slot •Versions with connectors or connection cable •Moulded cable ensuring very good strain relief •High protection rating for the ...

Honeywell linear/rotary potentiometers are designed to measure linear/rotary position and displacement. Reliable potentiometric technology was initially created for military applications ...

The AQ series of shaftless linear potentiometers represents a range of units for use in intrinsically safe environments according to Class I, II and III Division I, Groups A, B, C, D, E, F and G for hazardous (indoor/outdoor) ...

Supply voltage: 10 V - 30 V
Ambient temperature: -40 °C - 85 °C

Style Profile series Fastening detail Mounting clamps Housing material Aluminium, Anodized Magnets, number max. 1 Interface Quadrature Repeat accuracy ≤ 5 µm IP rating per IEC 60529 IP67

Measuring range: 1,700 mm
Linearity: 0 %
Supply voltage: 20 V - 28 V

Style Profile series Fastening detail Mounting clamps Housing material Aluminium, Anodized Magnets, number max. 1 pcs Connection Connector, M16x0.75, 8-pin Analog output Analog, current 4…20 mA Resolution ≤ 0.2 µA Repeat ...

Measuring range: 1,100 mm
Linearity: 0 %
Measuring rate: 1,000 Hz

Style Profile series Fastening detail Mounting clamps Housing material Aluminium, Anodized Magnets, number max. 1 Connection Connector, M12x1, 8-pin Analog output Analog, current 4…20 mA Resolution ≤ 700 nA Repeat accuracy ± ...

Measuring range: 25 mm - 7,620 mm

R-Series V - the new generation R-Series V is the successor to our current fourth generation. The new sensors have higher resistance to vibration and high temperatures, are ready for Industry 4.0 and fit perfectly ...

Measuring range: 50 mm - 3,000 mm

Temposonics E-Series ET is the ideal solution for usage in hazardous areas and in high temperature applications with a small and compact housing. Global approvals: ATEX / IECEx / CEC / NEC Compact installation dimensions High ...

Measuring range: 25 mm - 7,620 mm

... the first linear position sensors in the industry to meet SIL 2 standards. In addition, they are fully compliant with NEC, CEC, ATEX and IECEx Class I, II, III Division 1, Division 2 ...

Measuring range: 4,000 mm
Linearity: 0.1 % - 0.2 %
Ambient temperature: -40 °C - 85 °C

Protection class up to IP67/69 With inclination sensor in MEMS technology Optional redundant version Specifications Output - CANopen CANopen redundant Resolution - adjustable via CAN bus Sensing device - Magnetic ...

Measuring range: 6,000 mm
Linearity: 0.1 % - 0.2 %
Ambient temperature: -40 °C - 85 °C

Protection class up to IP67/69 With inclination sensor in MEMS technology Optional redundant version Specifications Output - CANopen CANopen redundant Resolution - adjustable via CAN bus Sensing device - Magnetic ...

Measuring range: 20,000 mm
Linearity: 0.1 % - 0.2 %
Ambient temperature: -40 °C - 85 °C

Protection class up to IP67/69 With inclination sensor in MEMS technology Optional redundant version Specifications Output - CANopen CANopen redundant Resolution - adjustable via CAN bus Linearity (position) ...

Measuring range: 50 mm

Bernstein teachable magnetic slot sensors are unique for their one or two freely programmable, independent switching points. These are built for standard C- and T- slots, and fit one slot. If used for only one output, ...

Measuring range: 600 mm

... encoder SG5 Miniature wire-actuated encoder with 600 mm measurement length Miniature wire-actuated encoder designed to capture linear measurement distances. Its measuring length of 600 mm is very long considering ...

Measuring range: 2,000 mm

Wire-actuated encoder SG10 Miniature wire-actuated encoder for capturing measurement distances with a maximum measuring length of 2000 mm. Profile SG10: Compact design Universally applicable thanks to standardized interfaces Easy ...

Measuring range: 2,000 mm

Wire-actuated encoder SG20 Compact wire-actuated encoder with a max. measurement length of and an analog output. Profile SG20: Compact design Universally applicable thanks to standardized interfaces Easy mounting Potentiometer, ...

Measuring range: 50 mm - 900 mm

Due to its high resolution also when measuring long distances, linear displacement measurements up to 900 mm can be carried out. Conversions between rotatory and translation movements through ball screws, ...

Measuring range: 50 mm - 1,250 mm

... wire position transducer is designed for industrial applications. The instrument is compact in size and has short assembly time. The device is also easy to customize and hence offers economical solution ...

Measuring range: 1,000 mm - 3,000 mm

Ranges from 1000 to 3000 mm Linearity max. ±0.02 % Output analog 0...10 V, 4...20 mA, Potentiometer Output digital TTL, HTL, SSI, Profibus, CANopen, DeviceNet, Ethercat, Profinet Protection class IP65 (optional IP67)

Measuring range: 3,000 mm - 5,000 mm

Ranges from 3125 to 6000 mm Linearity max. ±0.02 % Output analog 0...10 V, 4...20 mA, Potentiometer Output digital TTL, HTL, SSI, Profibus, CANopen, DeviceNet, Ethercat, Profinet Protection class IP65 (optional IP67)

The 600 series from BEI Sensors, is an enclosed linear motion position transducer. It has a shaft and threaded drive interface, and can accommodate a range of motion from 25.4 mm to 304.8 ...

The 9600 Series Linear Position Sensor, is designed for a variety of space limited feedback applications that require high accuracy. It is ideally suited for Industrial, vehicular, appliance, ...

Measuring range: 0 mm - 40,000 mm

"The CD series is available in ranges from 700 and 50,000 mm in a variety of incremental and absolute output options. In addition, models in this series are available with incremental, potentiometer, or absolute output (except CD046, ...

Measuring range: 20 cm - 800 cm

PL60 Reading head for interpolator MJ100 and for SL331 tape scale Compatible with interpolator: MJ100/MJ110 Max. response speed: 720m/min with 2µm resolution with MJ100 Max. resolution: 2µm (phase to phase) Easy installation Design ...

Supply voltage: 5 V
Ambient temperature: 0 °C - 45 °C

PL101 Reading head for SL700 series with 1Vpp, TTL or serial interface Reading head for SL710/720/730 magnetic tape scale Pl101-R/RH: 1Vpp interface PL101-RA/RHA: TTL line driver interface (RS422) PL101-RM/RHM/RP/RHP/RY/RHY: with ...

Measuring range: 5 cm - 3,000 cm
Supply voltage: 5 V - 30 V
Ambient temperature: 0 °C - 45 °C

PL81, PL82 Series with TTL output signal for SL110 and SL130 magnetic tape scales Reading head for SL110 / SL130 magnetic tape scale PL81: TTL by Open collector output PL82: A/B-phase by TTL line driver interface (RS422) Max. response ...

Measuring range: 50 mm - 1,000 mm
Measuring rate: 1 Hz - 1,000 Hz

Product Description Magtrol’s line of Displacement Transducers provide contactless measurement of absolute piston position in hydraulic and pneumatic cylinders and other applications. Their robust ...

Measuring range: 8 mm - 15 mm

... high accuracy due to its good linearity. In the displacement sensor series MM(R)10 the mechanical detection of linear movement is done by a rear and front guided push rod. The displacement sensor ...

Measuring range: 10 mm - 30 mm

... This compact sensor will be mounted by means of the pilot ring and the two thread holes on the front side. The mechanical detection of linear movement of the linear sensor ...

Measuring range: 50 mm - 200 mm

The potentiometric displacement sensor series MBX is excellently suited for very limited installation space due to its extremely flat design with an overall height of only 7 mm. In addition, the universal cursor can be ...

Measuring range: 9, 20 mm

... SOFTWARE Complete LabView application software included, with many features QUAD-4TRACK The QUAD-4TRACK is a laser position sensing system designed to support our unique pyroelectric quadrant detectors, ...

Measuring range: 9, 20 mm

... SOFTWARE Complete LabView application software included, with many features QUAD-4TRACK The QUAD-4TRACK is a laser position sensing system designed to support our unique pyroelectric quadrant detectors, ...

Measuring range: 9, 20 mm

... SOFTWARE Complete LabView application software included, with many features QUAD-4TRACK The QUAD-4TRACK is a laser position sensing system designed to support our unique pyroelectric quadrant detectors, ...

Measuring range: 0 mm - 15 mm

... optical light. Afterwards a CMOS linear sensor was added as the light-sensitive element to enable visual perception for workpiece position. These functions enable the K1G to detect small ...

Measuring range: 1,000 mm

Absolute position transducers for high dynamic positioning tasks. Inductive measurement principle, touchless position detection with free position markers; unlimited ...

Measuring range: 4,250 mm

Absolute position transducers in robust profile design; NOVOSTRICTIVE non-contacting, magnetostrictive measurement principle, non-contact position detection with free position ...

Measuring range: 5 mm - 50 mm

Absolute position transducers in compact, flat design. Non-contacting NOVOHALL measuring principle; Touchless position detection with position marker; Unlimited mechanical ...
