Laser fork light barrier PSL-25-80/W-3-P

• Fork width: 25 mm, fork depth: 80 mm • Switching function normally open / normally closed (NO/NC) • Connection: M8 plug, 3-pin Mechanical properties Wavelength 650 nm, red light Metrological characteristics Repeating accuracy, maximum 0.02 mm Electrical properties Operating voltage 12 … 24 VDC Output signal type Digital (PNP) Maximal current consumption 30 mA Circuit Chopped light trigger Load current 200 mA Laser output power <1 mW, laser class 2 Dynamical properties Frequency 4 kHz
