Rubber-tired forestry harvester 911-8

Overview
An agile harvester designed for efficient thinning and lighter final felling. Equipped with a robust crane and larger wheels, it maintains stability and productivity when working in challenging terrain, including obstacles and snow. Productive harvester suited for a wide range of thinning and mixed operations. 240H crane with 8.7 / 10 / 11 m reach. Choose from a range of options to customise the machine for comfort and productivity.

Highlights

• Power: 190 kW @ 1850 rpm (EU Stage V, Tier 4F)
• Gross lifting torque: 241 kNm (177,752 lbf-ft)
• Max tractive effort: 193 kN (43,386 lbf)
• Weight: From 20 182 kg (44,494 lb)

Dimensions
A. Width: With 600/55x26,5 tyres: 2 726 mm (8'11")
B. Length, total: 7530 mm
C. Length, front axle to middle joint: 1 930 mm (6'4")
D. Length, middle joint to rear axle: 1 800 mm (5'11")
E. Transport height: Straight cab: 3930–3995 mm (depending on options). Transport position (cab max rear tilt, crane forward, light ramp tilted): 3910 mm
F. Ground clearance at steering joint: 680 mm
Note: Stated dimensions are nominal and may vary slightly depending on production tolerances and choice of equipment.

Engine

• Type: AGCO Power 75FSTN-D5, 6-cylinder diesel engine with turbo and intercooler
• Stroke volume: 7.5 l (1.98 gal)
• Power: 190 kW @ 1850 rpm (EU Stage V, Tier 4F)
• Torque: 1 130 Nm @ 1 500 rpm
• Fuel tank: 405 l (107 gal)

Boom

• Model and reach: 240H: 8.7 / 10 / 11 m (28'6.5" / 32'9.7" / 36'1")
• Gross lifting torque: 241 kNm (177,752 lbf-ft)
• Gross slewing torque: 240H: 47.5 kNm (35,034.2 lbf ft)

Heads
Available heads: S92, C93, C124, S132, C144

Hydraulic system
Flow: 367.5 l/min @ 1470 rpm
System pressure: 280 bar

Electrical system
Voltage: 24 V
Battery capacity: 2 x 185 Ah
Generator: 200 A

Transmission
Driving speed: 0-25 km/h (0-15.6 mph)
Tractive force: 193 kN (43,386 lbf)

Notes
The specifications describe possible equipment, not which equipment is standard or optional. Standard and optional equipment varies between countries. Weights are based on the equipment specified in the basic specification. Specifications and designs are subject to alteration without prior notice.

Caractéristiques / spécifications techniques

• Model: 911-8
• Brand: Komatsu
• Power: 190 kW @ 1850 rpm (EU Stage V, Tier 4F)
• Engine type: AGCO Power 75FSTN-D5, 6-cylinder diesel, turbo + intercooler
• Stroke volume: 7.5 l
• Torque: 1 130 Nm @ 1 500 rpm
• Fuel tank capacity: 405 l
• Boom: 240H with reach options 8.7 / 10 / 11 m
• Gross lifting torque: 241 kNm
• Gross slewing torque (240H): 47.5 kNm
• Available harvester heads: S92, C93, C124, S132, C144
• Hydraulic flow: 367.5 l/min @ 1470 rpm
• Hydraulic system pressure: 280 bar
• Electrical voltage: 24 V; Battery: 2 x 185 Ah; Generator: 200 A
• Driving speed: 0-25 km/h
• Max tractive effort / tractive force: 193 kN
• Approx. weight: From 20 182 kg
• Dimensions (selected): Width with 600/55x26,5 tyres 2 726 mm; Total length 7530 mm; Front axle to middle joint 1 930 mm; Middle joint to rear axle 1 800 mm; Ground clearance at steering joint 680 mm
