Hydraulic cylinder BCDT2025pistonsingle-actingbrake
Add to favorites
Compare this product
Characteristics
- Type
- hydraulic
- Technology
- piston
- Configuration
- single-acting
- Applications
- brake
- Other characteristics
- standard
- Stroke
75 mm
(2.953 in)- Pressure
200 bar
(2,900.8 psi)- Rod diameter
25 mm
(1 in)
Description
Unit
-
Each
-
Specifications
-
Combination of a standard pneumatic brake cylinder and single-acting hydraulic cylinder
-
Benefits
-
Suitable for both hydraulic and pneumatic control of the brake axle
-
Application
-
For hydraulic and pneumatic braking of trailers without external suspension
-
Properties
-
Integrated spring balancer
Quick reaction time on impact
Ready-to-use
-
Consists of
-
Brake cylinder
Fork
-
Application category
-
Brake
-
Type
-
Single acting
-
A
-
176 mm
-
Connection
-
M16x1,5 (2x)
-
Diameter bolt
-
14 mm
-
Length bolt
-
176 mm
-
Nominal pressure
-
200 BAR
-
Piston rod diameter
-
25 mm
-
Connection
-
3/8" BSP
-
Stroke
-
75 mm
-
Surface treatment
-
Zinc-plated
-
Max. working pressure
-
250 BAR
