Liquid tensiometer JYW-200A

digitalfor surface and interfacial tension measurement

The tensiometer is mainly to test surface tension of all kinds of liquids just like water, oil liquid chemicals and so on. It is widely used in the petroleum, chemical industry, research department and university. This instrument is composed by platinum ring , torsion wire, differential transformer and data procession system according to the ISO 1409 and ASTM D971 standard. Model：JYW-200A Test range：0-200.0 mN/m Resolution：0.1 mN/m Accuracy：±2% Sample Stroke：25mm Sample speed：15 mm/min±2 mm/min PT Ring Radius：0.3 mm PT Ring Perimeter：60mm Sample Cup Dia.：56 mm Sample Cup volume：60 ml Dimension：400mm×220mm×350mm Weight：14kg Power：1P~220V/110V， 50/60Hz
