Optical distance sensor ODS9L2.8/LAK-450-M12

digitalanalogscanning

Application - Fill-level monitoring Length measurement in material cutting Object measurement Type of scanning system - Against object Special version - Activation input Deactivation input Teach input Light source - Laser, Red Laser class - 2, IEC/EN 60825-1:2014 Light spot size [at sensor distance] - 1 mm [450 mm] Measurement range - 50 ... 450 mm Resolution - 0.1 mm Accuracy - 1 % Reference value, accuracy - Measurement distance Reproducibility (1 sigma) - 0.1 mm Referencing - No Optical distance measurement principle - Triangulation Supply voltage UB - 18 ... 30 V, DC Number of digital switching inputs - 1 Piece(s) Function - Activation input Deactivation input Teach input Trigger Number of analog outputs - 1 Piece(s) Number of digital switching outputs - 1 Piece(s) Type - Configurable, factory setting: current Switching element - Transistor, Push-pull Type - IO-Link Specification - V1.1 Type of connection - Connector, Turning, 90° Thread size - M12 Material - Plastic No. of pins - 5 -pin Dimension (W x H x L) - 21 mm x 50 mm x 50 mm Housing material - Plastic Lens cover material - Glass Net weight - 50 g
