Switching relay module LBK ISC BUS PS

DIN rail mountedUSB

Application - Stationary access guarding Stationary danger zone guarding Functions - Changeover between configurations Connection of up to 6 sensors Deactivation of sensor groups Start/restart interlock (RES), selectable Synchronization of controllers SIL - 2, IEC 61508 SILCL - 2, IEC/EN 62061 Performance Level (PL) - d, EN ISO 13849-1 MTTFd - 44 years, EN ISO 13849-1 PFHD - 4.5E-08 per hour Mission time - 20 years, EN ISO 13849-1 Category - 3, EN ISO 13849-1 Supply voltage UB - 20 ... 28 V, DC Number of safety-related switching outputs (OSSDs) - 2 Piece(s) Function - Parameterization Function - Process PROFINET device - Device acc. to Spec V2.3.5 Network load class - III Security level - 1 Switch functionality - IRT-ready 2-port switch acc. to IEEE 802, integrated in connection unit Safety-related switching signals - 4 Piece(s) PROFIsafe version - V2.4 V2.61 Type - USB Number of connections - 7 Piece(s) Function - Voltage supply Type of connection - Terminal Type of terminal - Screw terminal No. of pins - 3 -pin Function - BUS OUT Type of connection - Terminal Function - Signal IN Signal OUT Type of connection - Terminal Dimension (W x H x L) - 105 mm x 58 mm x 103 mm Net weight - 250 g Housing color - White Snap-on mounting Ambient temperature, operation - -30 ... 60 °C Ambient temperature, storage - -40 ... 80 °C Relative humidity (non-condensing) - 0 ... 95 % Protection class - II Approvals - TÜV Süd Italia UL
