Temperature control module MSI 430-03

output

Series - MSI 430 Number of safe I/Os - 16 IN, 4 OUT, 4 programmable I/O 4 configurable safe I/Os (via software) 24 safe I/Os 40 certified function modules Expandable with up to 12 I/O modules Freely configurable with MSI.designer (license-free) Program memory in SD card format (512 MB) Switching current 4 A per output Transfer of diagnostic data via external fieldbus gateways Up to 300 function modules in a project SIL - 3, IEC 61508 SILCL - 3, IEC/EN 62061 Performance Level (PL) - Up to and including e, EN ISO 13849-1 PFHD - 4,3E-09 per hour Category - 4, EN ISO 13849 Supply voltage UB - 24 V, DC, -30 ... 25 % Power consumption, max. - 3.3 W Number of outputs - 4 Piece(s) Number of configurable inputs/outputs - 4 Piece(s) Short circuit protection, outputs - Yes Nominal output current per output, max. - ≤ 12 A / 8 ms Number of inputs - 16 Piece(s) Voltage permitted at the input - HIGH: 13 … 30 V LOW: -5 … +5 V Input current at signal 1 - HIGH: typ. 2.3 mA / max. 6 mA LOW: < 2 Function - Configuration via software Function - Configuration via software Number of connections - 3 Piece(s) Function - Signal IN Signal OUT Voltage supply Type of connection - Terminal Type of terminal - Spring-cage terminal No. of pins - 32 -pin Function - BUS OUT Connection cross sections - 2 x 0.2 to 1.5 mm², wire 2 x 0.25 to 1.5 mm², wire with wire-end sleeve (pressed in trapezium shape) Dimension (W x H x L) - 45 mm x 107 mm x 121 mm Net weight - 290 g Housing color - Gray Type of fastening - Snap-on mounting Ambient temperature, operation - -25 ... 65 °C Ambient temperature, storage - -25 ... 70 °C Relative humidity (non-condensing) - 10 ... 95 %
